LA-3116 Portable Road Signs Retro reflectometer for Road markings testing
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
Reverse Reflection Coefficient Detector for Pavement Markings & Traffic Signs Testing
-
Reflectometers for Pavement Markings & Traffic Signs Testing
-
Casagrande Soil Testing Atterberg Consistency Liquid Limits Test Apparatus
-
Concrete Thickness Measuring Instrument Gauge Concrete Detector Concrete Slab Thickness Gauge
-
High quality Concrete Thickness Measuring Instrument Gauge Floor Slab Thickness Gauge cheap price
-
Convenient Digital Concrete Integrated Floor Slab Thickness Gauge Concrete Thickness Gauge for sale
Product Description
LA-6116 Road Markings Reflectance Coefficient Measuring Instrument
Usage Overview
LA-6116 Road Marking Lines Retroreflective Measuring Instrument. The upgraded version of our company on the original marking line is an open optical path portable field measuring instrument which is used to measure the retroreflective brightness coefficient of the marking line.
Measurement item | retroreflective brightness coefficient mcd.m-2.lx-1 |
Measurement range | 0-4000 |
Observation angle | 1.05 ° |
Incidence angle | 88.76 °, complementary angle is 1.24 ° |
Color temperature of light source | 2856 ± 50K |
Measurement aperture area | 200mm x 95mm |
Repeatability measurement error | ≤2% |
Continuous working time of battery | > 30h |
Data storage space | 8GB |
Built-in battery capacity | 12V / 13Ah |
Charging power supply | DC 15V |
Working environment temperature | -15 ℃ ~ + 60 ℃ |
Ambient humidity | <98%, no frost |
Volume of the whole machine | 360mm x 135mm x 173mm |
Detailed Images
wet and continuous rainfall.
The unit is mcd · m-2 · lx-1. The main characteristics of its research: it simulates the motor vehicle driving on the road at night, the headlights illuminate the road (made of retro-reflective materials), and after being reflected, the brightness observed by the driver in the cab.
The measured parameter is the nighttime retroreflective brightness coefficient, or RL value.
