Intelligent Soil Foundation Coefficient Tester

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

GTJ-K/WK Intelligent Ground Vehicles Tester

Usage Overview

GTJ-K/WK plate load test set can be used to test the foundation coefficient of coarse, fine soil and compacted roadbed, base course, etc. It can also be used to calculate the deformation modulus of uniform foundation soil. Test the stress and deformation characteristics of foundation soil, determine the foundation coefficient of railway, highway roadbed, roadbed, etc. The product has the function of testing K30,K40,K60. In order to meet the requirements of railway informationization, our company jointly with experts of railway department, breaking the traditional old test method, intellectualized the foundation coefficient tester, greatly improved the test accuracy and efficiency, and the product quality reached the international advanced level.

Product Description

1.It is the first data processing method of APP in China. It realizes data wireless collection and transmission. It also provides cloud transmission ports for docking engineering detection and management system. It provides reliable data sources for real-time data collection, online data analysis and large data management.
2.Imported sensors and some components are used, which has high test accuracy and more reliable test data.
3.Imported cylinders and manual pumps are adopted, with outstanding performance of pressure control and voltage stabilization.
4.The displacement acquisition device adopts heavy profile and three-point support design, which has strong seismic and windproof capability and ensures accurate data.
5.Displacement acquisition data: single point acquisition of load plate center, data more objective and accurate;
6.The wireless Bluetooth micro printer can print directly on the spot to ensure the accuracy and objectivity of the test results.
7.Direct display of load strength and settlement value, automatic calculation of K30, K40, K60 value, and display pressure and settlement curve.

Specification

	Production	WK	K
Test scope of application	Applicable Soil Types	Soil-rock mixed fillers with particles size less than 1/4 of the diameter of bearing plate	Soil-rock mixed fillers with particles size less than 1/4 of the diameter of bearing plate
		Test impact depth	0~500mm	0~500mm
		work environment	Temperature-10~40℃ Humidity＜90%HR	Temperature-10~40℃ Humidity＜90%HR
Handheld host	Specification	Huawei Mobile Phone	Screen size: 3 inches
				Screen size: 5 inches	Volumn: 100x205x40mm
				Volume: 145x70x10mm	Weight: 0.8kg
				Weight: 110g	Handheld Host
		Storage capacity	Depending on the memory of the phone. 10G storge capacity	400 sets of test data
		Data transmission mode	Data wireless transmission; data cloud transmission	Data line transmission
		Powder supply mode	Depending on the cell phone battery	Large capacity lithium battery, working time is more than 18 hours
		Display mode	Mobile App mode, Chinese and English switching display	Handheld host screen, Chinese and English switching display
Printer	Connection mode	Wireless Bluetooth Printing	Wireless Bluetooth Printing
Sensor	Pressure Sensor Range	100kN	100kN
Sensor		Displacement sensor range	25mm, Resolution 0.01mm	25mm, Resolution 0.01mm
Data Acquisition Device	Bearing plate	Diameter: 300mm	Diameter: 300mm
				Thickness: 25mm	Thickness: 25mm
				Weight: 17.5kg	Weight: 17.5kg
		Loading device	Hydraulic Pump: Pressure 100kN	Hydraulic Pump: Pressure 100kN
				High Pressure Hose: Length 2m	High Pressure Hose: Length 2m
				Pluggable pressure cylinder connecting rod: 1x 40mm.	Pluggable pressure cylinder connecting rod: 1x 40mm.
				1x90mm, 1x120mm	1x90mm, 1x120mm
				1x160mm, 2x60mm	1x160mm, 2x60mm
		Settlement measurement device	Three-point bracket(with retractable)	Three-point bracket(with retractable)
				Rotary lever arm. adjustable base	Rotary lever arm. adjustable base
				Dimension: 2320x570x420mm	Dimension: 2320x570x420mm
				Weight: 7.0kg	Weight: 7.0kg
Packing specification	Host box	Material: Engineering plastics	Material: Engineering plastics
				Volume: 470x360x170mm	Volume: 470x360x170mm
				Weight: 7.0kg	Weight: 7.0kg
		Outer packing box 1	Material: Aluminum alloy	Material: Aluminum alloy
				Volume: 1410x510x260mm	Volume: 1410x510x260mm
				Weight: 72kg	Weight: 72kg
		Outer packing box 2	Material: Aluminum alloy	Material: Aluminum alloy
				Volume: 1270x440x230mm	Volume: 1270x440x230mm
				Weight: 32kg	Weight: 32kg

Unpacking display

Our Advantages

Installation and training

· If buyers visit our factory and check the machine, we will teach you how to installand use the machine, and also train your workers/technician face to face.

· Without visiting, we will send you user manual and video to teach you to install and operate.

After Service

· One year guarantee for whole machine.

· 24 hours technical support by email or calling

Any questions, please contact me without hestitation, welcome your inquiry!Price can be negotiated

our customer

Company Profile

` Cangzhou Lovely Group Co.,Ltd. is a professional manufacturer specializing in Testing Equipment,Universal Testing Machine ,Asphalt Tester,Test Moldsand Soil Road Lab Tester,supply verious type of products ..... We assure high quality to you.

· All our products are made in China .Excellent quality with competitive price

Packing & Delivery

· Tianjin port or Qingdao Port deliver by sea and Also can ship by air via express company

FAQ

Q1: Are you a factory or trading company? A: We are a factory specializing in manufacturing all kinds of scaffolding material.
Besides, we could also purchase products as request.

Q2: Where is the loading port?
A: Tianjin port or Qingdao Port.

Q3:How to choose the Transportation Term? A:Usually,we may according to your needs,we may choose the most rasonable freight,then
to select for you.

Q4: What certificates do you have?
A: We have ISO 9001, CE, SGS.

Q5: Do you have an OEM service?
A: Yes. We can provide OEM services according to your requirements.

Q6: What are the payment terms?
A: T/T payment is preferred and other could be accepted, such as L/C, D/P, Western Union, PayPal etc. It is negotiable.
