Product Usage and Features
F800 Wireless Crack Measuring Device
USAGE OVERVIEW:
It is used for automatic measurement of crack width and crack depth on structure surface, automatic interpretation and storage of data.
PRODUCT FEATURES:
1.New upgraded wireless cloud transmission function;
2.Original wireless camera probe, snap button operation is convenient; host adopts Android system tablet computer, English/Chinese full touch operation;
3.Intelligent interpretation of oblique cracks, without vertical; images can be zoomed in and out, and the interface display scale can be manually assisted to interpret;
4.The bracket has scale on it, large capacity tablet and TF card storage;
5.The host can analysis data and generate report form without transferring to the upper computer.
Parameters
Master control unit |
8-inch tablet Android operating system |
||
Wireless Width Gauge Unit |
Test range and accuracy |
0~10mm: 0.01mm |
|
Magnification |
Digital 60 times |
||
Operational mode |
Touch screen + shortcut keys |
||
Connection mode |
Wifi connection |
||
Data transmission mode |
Wireless cloud transmission (optional) |
||
Measuring method |
Automatic/ manual |
||
Power supply mode |
Built-in lithium battery |
||
Working hours |
More than 10 hours |
||
Working environment |
-10℃~ 40℃ ＜90%RH |
||
Wireless Depth Gauge Unit |
Test scope |
5~500mm |
|
Measurement accuracy |
Less than 5mm or 2%~10% of the actual depth |
||
Operational mode |
Touch screen + probe automatic trigger |
||
Connection mode |
Bluetooth connection |
||
Data transmission mode |
Wireless cloud transport(options) |
||
Measuring method |
Fast/standard measurement |
||
Power supply mode |
Built-in lithium battery |
||
Working hours |
More than 10 hours |
||
Packing dimensions |
420*140*335mm |
||
Detailed Images
Probe:
Original wireless camera probe.
Operation:
The 8 inch host adopts Android system with English full touch operation. Images can be zoomed in and out.
Report:
The host can analysis data and generate report form without transferring to the upper computer.
