Application
AT802 Glow Wire Tester
AT802 Glow Wire Tester uses the specified material Ni/Cr(80/120) and shape wire to testing temperature (550℃~960℃) by large current in 1min, use specified pressure (1.0N) vertical iron the specimen 30s. Then observe if the specimen is ignited or burning time to determine the fire risk of electric product, insulation material etc.
Feature
★ Using digital instrument control system, import control components;
★ Fixture made of high quality stainless steel, corrosion-resistant, no rust;
★ One-button time device, to facilitate the use of equipment, simple operation;
★ Advanced temperature control and temperature measurement system, so that the test more accurate, the results more reliable;
★ Tempered glass observation window, the entire test process can be observed
Technical specification
Model | AT802 | ||
Glow wire | 4mm ± 0.04mm Ni/Cr(80/120) | ||
Glow wire temp. | 500 ℃ ～ 1000 ℃ | ||
Test pressure | 1.0N±0.1N | ||
Max iron depth | 7mm ± 0.5mm | ||
Sample moving speed | 10mm /s ～ 25mm /s | ||
Test time | 1s ～ 999.9s | ||
Test space | 0.5m3 | ||
Background illumination | ≤ 20Lx | ||
Power supply | AC220V, 50Hz |
Our Company
Packing & Delivery
Packaging | ||
Packaging Details | 1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. | |
Payment
Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment | ||||
FOB | |||||||
CFR(C&F) | 30% T/T in advance, paid the balance against copy of B/L | ||||||
CIF | |||||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||||
West Union | Amount lower than 5000usd | ||||||
West Union | |||||||
Delivery Time | 7~10days after receiving payment for one container | ||||||
