Product Description
AT801 Melting Poit Tester
AT801 Melting Point Tester is for the analysis of organic materials in textile, chemical fiber, building materials, medicine, chemical industry, etc. You can clearly observe the physical changes such as morphology, color change and three-state transformation under the microscope.AT801 Melting Point Tester is for the analysis of organic materials in textile, chemical fiber, building materials, medicine, chemical industry, etc. You can clearly observe the physical changes such as morphology, color change and three-state transformation under the microscope.
Specification
Model | AT801 | |
Melting point measure range | RT-320℃ | |
Resolution | 0.1℃ | |
Measurement repeatability | ± 1 ° C (at <200 ° C) | |
± 2 ° C (at 200 ° C-300 ° C) | ||
Linear heating rate | 0.5,1,2,3,5 (° C / min) | |
Microscope magnification | ≤ 100X | |
Suggested using environment | 0 ~ 40 ºC; 45 ~ 85% RH | |
Weight | 10kg | |
Power | 220V 50Hz |
Details and Features
★Using high-definition CCD camera and LCD, can clearly observe the melting process of the sample;
★Using PID algorithm to control heating, to ensure the stability of temperature rise rate;
★Can automatically measure, man-machine integration, unattended during the test, thus liberating productivity, improve the efficiency of the test;
★Friendly interface, measurement data can be backtracking (temperature rise, melting point, light curve, the test image can be stored), to reduce the disputes;
★Optimization of structural design, accurate positioning;
★With two measure methods: microscopic method and light amount method, the light amount method automatically calculates the results;
★It applicable to a wide range: such as medicine, chemicals, building materials, textiles, chemical fiber, etc. ★Using high-definition CCD camera and LCD, can clearly observe the melting process of the sample;
★Using PID algorithm to control heating, to ensure the stability of temperature rise rate;
★Can automatically measure, man-machine integration, unattended during the test, thus liberating productivity, improve the efficiency of the test;
★Friendly interface, measurement data can be backtracking (temperature rise, melting point, light curve, the test image can be stored), to reduce the disputes;
★Optimization of structural design, accurate positioning;
★With two measure methods: microscopic method and light amount method, the light amount method automatically calculates the results;
★It applicable to a wide range: such as medicine, chemicals, building materials, textiles, chemical fiber, etc.
Our Company
Packing&Delivery
Packing | ||
Packaging Details | 1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. | |
Payment
Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment | |||
FOB | ||||||
CFR(C&F) | 30% T/T in advance, paid the balance against copy of B/L | |||||
CIF | ||||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | |||||
West Union | Amount lower than 5000usd | |||||
Delivery Time | 7~10days after receiving payment for one container | |||||
