HY7820TS Human Anti-slip Tester This machine is the simulation of human performance in non-slip walking process, the test person wearing a shoe test can be standing on a platform to change the tilt angle, and join the flow of the medium on the platform, when the inclination angle of the platform by slipping test and a dielectric species, to determine slip resistance of the shoes.
|
ISO 10545-17 |
DIN 51130, 51097 |
AS/NZS4586 |
Note: this Human Anti-slip Tester can conform to but not limit to all the standards above, for more standards conformance, please contact us.
1. Full touch screen control, large-screen display
2. Chinese (English) subtitles, easy to understand, does not appear to misuse.
3. industrial PLC control, anti-jamming performance, fast data transfer.
4. Special inching function, more convenient operation.
5. Related parameters are opening up the instrument to meet the testing requirements of different standards.
|
HY7820TS Human Anti-slip Tester |
|
|
Angle range |
0 ~ 40 ° |
|
The angle adjustment rate |
1 ° / S (adjustable) |
|
Control mode |
7-inch touch screen + IR remote control |
|
Panel Type |
Stainless steel, ceramic tile, marble, glass and other interface |
|
The number of medium circulation system groups |
4 |
|
Working table size |
1850mm × 1000mm |
|
Lift motor |
servo motor |
|
The liquid tank |
38Lx4 months |
|
Protection |
Auto-lock + manual rope belts |
|
Power |
AC220V 2KW 50HZ |
|
Dimension |
280x185x290cm |
|
Weight |
1400kg |
