Water Tank for the Hydrostatic Pressure Tester With Refrigerating System
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2012
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Product Description
AT470 Hydrostatic Pressure Tester is mainly used to determine time-to-failure of plastic pipe under constant internal pressure and also the resistance to hydrostatic pressure in a short time period.
Standard
ASTM D1598, 1599 | ASTM F1335 | ISO 1167, 9080, 1756, 13477 | ||
GB/T 15560, 18252, 6111 | CJ/T 108 | |||
Note: For more standards, please contact us | ||||
Specification
Model | AT470 | ||
Pipe diameter range | Φ10~Φ2000mm | ||
Working position | 6 positions (1~50 positions can be customized) | ||
Operation mode | Operation panel/PC control | ||
Pressure range | 0.2~10MPa (or customized) | ||
Pressure resolution | 0.001MPa | ||
Pressure control accuracy | -1%~+2% | ||
Measuring range | 5%~100% F.S. | ||
Timing range | 1s~10000h | ||
Timing accuracy | ±0.1% | ||
Display resolution | 1s | ||
Min. Time setting unit | min | ||
Temperature control system | RT-95℃ (15~95℃ with refrigerating system) | ||
Temperature control accuracy | ±0.5℃ | ||
Main body material | 304# stainless steel | ||
Power supply | Pressure control main machine | AC220V, 50Hz | |
Pressure workstation | 3phase, AC380V, 50Hz | ||
Constant temperature tank | 3phase, AC380V, 50Hz | ||
Details & Features
★ The main machine consists of pressure control unit, magnetic valve, sensor, pressure workstation, etc.
★ The dimension of test tank needed bases on the dimension of test pipes
★ The number of working position can be customized according to requirement, that is to say, the interface of pressure can be customized such as 3, 6 or 10
★ The dimension of test tank needed bases on the dimension of test pipes
MODEL | Dimensions (mm) | Power | ||||
L | W | H | (kw) | |||
110 | 750 | 450 | 700 | 6 | ||
160 | 1620 | 770 | 1305 | 9 | ||
250 | 1750 | 870 | 1675 | 9 | ||
400 | 2250 | 950 | 1450 | 12 | ||
630-710 | 2750 | 1370 | 1235 | 18 | ||
800-1000 | 3100 | 1670 | 1555 | 27 | ||
1200 | 3100 | 1950 | 1915 | 54 | ||
★ Refrigerating system optional. The test tank can be connected with refrigerating machine to perform low-temperature test, thus test temperature can be RT-95℃ or 15~95℃
★ Stainless end caps of different diameter can be selected according to customers’ requirement, the material is stainless steel or carbon steel
Stainless steel end caps | ||||
End closures | ||||
Specification | D16~D1600 | |||
Structure | Pan structure | |||
Sealing ring | O-ring | |||
Conversion connector | PT1/4, internal thread, stainless steel material | |||
End closures connector | M12*1.25, internal thread | |||
Pressure range | D16~D110mm | 0~10MPa (20MPa max. For D16/20/25 ) | ||
Φ125~Φ630mm | 0~5MPa | |||
Material | Stainless steel | |||
★ One microcomputer control one working position, it can separately set and control pressure, accuracy, time and other parameters while the computer does not work. Real-time display pressure, time and status (8 statuses: pressure rise, pressure compensate, pressure release, over- pressure, run, test over, leakage, burst) and also store these test data. It is also equipped with sound and light alarm when over-pressure, test over, leakage or burst happens
★ Imported (Germany) pressure control electric valve, two pieces for each working position, high accuracy
★ Imported (USA) water pressure station, excellent performance, long service life, low noise, no need to use air source
★ Adopt high precision sensor, the control accuracy can reach ±0.01MPa of set value
★ Can observe, analyze, check, store and print test curve (pressure-time), start time, set time, current time, effective time, ineffective time, remaining time, over-pressure time, pressure compensation time, etc.
Our Company
History
Since 1982 with more than 20 years’ experience
Warranty
Two Year Warranty for whole product
Training
Video and user manual for training
Onsite service
Installation and training service is available
Testing service
Free sample testing before order is available
Lead time
15 working days lead time for most product
Packing & Delivery
Packaging | ||
Packaging Details | 1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. | |
Payment
Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment | ||
FOB | |||||
CFR(C&F) | |||||
CIF | |||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||
West Union | Amount lower than 5000usd | ||||
West Union | |||||
Delivery Time | 7~10days after receiving payment for one container | ||||
