Home > Electrical & Electronics > Electric Motor > DC Motor > HG-KN13J-S100 Mitsubishi 0.1kw Rated Output Power Servo Modular

HG-KN13J-S100 Mitsubishi 0.1kw Rated Output Power Servo Modular

Name: HG-KN13J-S100 Mitsubishi 0.1kw Rated Output Power Servo Modular
Brand: Mitsubishi
SKU: 170974037
Availability: InStock

HG-KN13J-S100 Mitsubishi 0.1kw Rated Output Power Servo Modular thumbnail-1

HG-KN13J-S100 Mitsubishi 0.1kw Rated Output Power Servo Modular photo-1

US$ 1 - 1000000 MOQ: 1 Unit

Key Specifications

Get Latest Price

Brand Name:

Mitsubishi

Place of Origin:

Japan

Model Number:

HF-KN13J-S100

Contact Supplier Request Quote Chat Now

Huizhou Linchuang Technology Co ., Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

5 days

Product Details
Company Profile
Contact Us

Brand Name Mitsubishi

Place of Origin Japan

Model Number HF-KN13J-S100

Type Servo Motor

Certification CCC, CE

Usage Other, universal

Construction Permanent Magnet

Efficiency IE 3

Protect Feature Drip-proof

Voltage(V) 97V

Output Power 100W

Continuous Current(A) 0.8A

Speed(RPM) 3000R/MIN

Commutation Brushless

Detailed Product Description

Category:	Industiral Servo Motor	Model:	HG-KN13J-S100
Rated Output Power:	100w	Rated Speed:	3000r/min
Series:	HF-KN	Brand:	Mitsubishi
High Light:	ewing machine servo motor,electric servo motor

MITSUBISHI 100W Industrial AC SERVO MOTOR HG-KN13J-S100 Rated speed 3000r/min

Specifications

FUNCTIONS	PARAMETERS
Brand Name	Mitsubishi
Model Number	HG-KN13J-S100
Rated output (kW)	0.1
Rated torque (N.m)	0.32
Maximum torque (N.m)	0.95
Rated speed (r/min)	3000
Maximum speed (r/min)	5000
Rated current (A)	0.8
Maximum current [A]	2.4
Speed/position detector	17-bit encoder common to absolute position/incremental
Mass (kg)	0.74

Related Products:

Product Name: Rotary servo motor.
Model: HG-KN13J-S100.
Inertia/capacity: Low Mitsubishi HG-KN43J-S100 inertia, small capacity.
Rated output: 0.1 kW.
Rated speed: 3000 r/min.
Oil seal: Installed.
Electromagnetic Mitsubishi HG-KN43J-S100 brake: None.

Product Name: Rotary servo motor.
Model: HG-KN23J-S100.
Inertia/capacity: Low Mitsubishi HG-KN43J-S100 inertia, small capacity.
Rated output: 0.2 kW.
Rated speed: 3000 r/min.
Oil seal: Installed.
Electromagnetic brake: None.

Product Name: Rotary servo motor.
Model: HG-KN23BJ-S100
Inertia/capacity: Low inertia, small capacity.
Rated output: 0.2 kW.
Rated speed: 3000 r/min.
Oil seal: Installed.
Electromagnetic brake: Installed.

Product Name: Rotary servo motor.
Model: HG-KN43J-S100
Inertia/capacity: Low inertia, small capacity.
Rated output: 0.4 kW.
Rated speed: 3000 r/min.
Oil seal: Installed.
Electromagnetic brake: None

Product Name: Rotary servo motor.
Model: HG-KN73J-S100.
Inertia/capacity: Low inertia, small capacity.
Rated output: 0.75 kW.
Rated speed: 3000 r/min.
Oil HG-KN43J-S100 seal: Installed.
Electromagnetic brake: None.

Corresponding servo amplifier: MR-JE-10B/MR-JE-10A.
Support position control, speed control, torque control, push and press control.
Position control can use linear, arc interpolation controller, fixed size feed control, target position change and other rich functions.
The position control and torque control are realized by switching control mode.
The gain adjustment of servo can be simply performed by the advanced one key tuning function.
At the same time, it is also able to suppress the low frequency vibration of the manipulator by the advanced vibration suppression control II,
Shorten the time to complete the positioning, so as to achieve the production of the rhythm of the shortening.
