Full Automatic Filament Extension Force Tester
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2012
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Manufacturer Fiber Opening Machine With High QualityNegotiableMOQ: 1 -
EN 143 EN 149 Filter Mechanical Strength TesterNegotiableMOQ: 1
-
High Quality Yarn Sample Card Winder PriceNegotiableMOQ: 1
-
Fiber Melt Spinning Machine for Small Batch Production TestNegotiableMOQ: 1
-
CRE Single Yarn Strength Tester ASTM D2256NegotiableMOQ: 1
Product Description
HY0367 Full Automatic Filament Extension Force Tester is used to determine the extension force developed while drawing a partially oriented filament yarn (POF) between two pairs of draw rolls of different surface speeds. Extension force provides an estimate of the yarn orientation and direct reflect the dyeing property of DTY in the following process.
Specification
Model |
HY0367 |
Load cell |
1000cN |
Force resolution |
0.01cN |
Force accuracy |
≤±0.5% |
Extension resolution |
0.01mm |
Draw roll speed |
(10~400)mm/min, randomly adjustable |
Pretension range |
(0.5~50)cN |
Draw ratio |
1.6 |
Effective length |
950mm |
Temperature range |
Room temperature~300℃ |
Air pressure required |
0.4Mpa~0.6Mpa |
Test data |
Mean, maximum, minmum, SD, CV, Q95, curves and distribution graph |
Power supply |
AC220V 50Hz, 5W |
Dimensions |
1100×630×1770mm(L×W×H) |
Our Company
History
Since 1982 with more than 20 years’ experience
Warranty
Two Year Warranty for whole product
Training
Video and user manual for training
Onsite service
Installation and training service is available
Testing service
Free sample testing before order is available
Lead time
15 working days lead time for most product
Packing & Delivery
Packaging |
||
Dimensions |
1400*900*1600mm |
|
Weight |
200kg |
|
Packaging Details
|
1. The equipment is covered with film is protect it from water vapour during the trip.
2. The box is filled with foam to protect the equipment from impact.
3. Exported wooden box made from plywood, don't need fumigated.
|
|
Payment
Payment Term
|
T/T
|
EXW |
30% T/T in advance, paid the balance before shipment
|
||
FOB |
|||||
CFR(C&F) |
|||||
CIF |
|||||
L/C |
L/C amount above 50,000 usd, we can accept L/C at sight |
||||
West Union |
Amount lower than 5000usd
|
||||
West Union |
|||||
Delivery Time |
7~10days after receiving payment for one container |
||||
