Product Description
AT277 Sample Size Garment & Ribbon Dyeing Machine is suitable for dyeing, finishing and washing of knitted products such as woolen sweater, nylon, acrylic, cotton and rayon.
Product Structure:
Equipped with new dyeing machine dedicated computer, precision of the heating system, accurate temperature control and time control, help to improve the working efficiency.
Application:
Specification
Model | AT277 Series |
Temperature control range | RT~99℃ |
Cages size | φ350*300 orφ350*600 |
Capacity | 2kg/4kg |
Bath ratio | 1:10-1:20 |
Heating mode | Electric heating |
Heated medium | Water (recommended use of distilled water) |
Heating power | 3.25KW/10.75KW |
Speed | 0-40rpm/min |
Dimensions | 850*500*1060mm or 1200*680*1100mm |
Power | 380V, 50Hz |
Details & Features
★ Microcomputer control heating temperature
★ Stainless steel exterior design, nice appearance
★ The precise inversion controller is used to automatically control the operation of positive and negative, so that the cylinder fabric can be uniformly turned to ensure uniform dyeing of the fabric.
★ The bottom of the cylinder is equipped with electric heating pipe, which is convenient and safe to operate.
★ The rotational speed is adjustable from 0-40 RPM.
★ Automatic control of the positive and negative turn.
