Mini Lab Roving Frame Of Mini Spinning System With 1 Spindle
- T/T Credit Card
You May Like
Product Description
AT205 Mini Lab Speed Frame is part of the mini spinning system. It’s mainly used in university, researching center etc. and it is used to make roving from sliver. And in the same time, insert the twist into the roving and then winding the twisting roving on bobbin.
1.AT205 Mini lab Speed Frame adopts touch screen and PLC control.
2. Imported frequency converter of high efficiency.
3.Mini type machine, save researching cost and easy to operate and maintain.
4.AT205 Mini lab Speed Frame Can be used for cotton fiber or wool fiber (alternative) with different machine parts.
|
AT205 Mini Lab Speed Frame |
|
|
Spindle number |
1 |
|
Fiber type |
Cotton or wool (alternative) |
|
Twisting range |
50-250 twist/m |
|
Drafting range |
Approx. 2~50 |
|
Fiber length |
22 ~ 42 mm or customized |
|
Output capacity |
0.25 ~ 1 kg per hour or customized |
|
Roller diameter |
Φ28/25/28mm |
|
Output speed |
Approx. 12m/min |
|
Spindle flyer speed |
600rpm |
|
Can size |
|
|
Power |
220V/380V, 50/60Hz, 700W |
|
Dimension |
1000*800*1600mm |
