Module spare parts 6410-024-N-N-N

Focus on DCS, PLC, robot control system and large servo system.

Main products: various modules / cards, controllers, touch screens, servo drivers.

Advantages: supply of imported original products, professional production parts,

Fast delivery, accurate delivery time,

The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

Humidity 93%, 40° C, 4 days IEC 60068-2-3 (1969) Seismic test 2 g, 30 s, 1 to 33 Hz (1 octave/min) IEC 60255-21-3 (1995), IEEE 344 (1987) Leakage resistance >100 MΩ, 500 V DC EN 60255-5 (2001), IEC 60255-5 (2000) Insulation test 2 kV, 50 Hz, 1 min 2.2 kV, 50 Hz, 1 s 2.85 kV, DC, 1 min 3.2 kV, DC, 1 s 1 kV across open contacts Second test multiplication x 0.75 (Voltage) EN 60255-5 (2001), IEC 60255-5 (2000), EN 60950 (1995) Surge voltage test 5 kV, 1.2/50 µs EN 60255-5 (2001), IEC 60255-5 (2000) * 1 MHz burst disturbance test 1.0/2.5 kV, Cl. 3; 1MHz, 400 Hz rep.freq. IEC 60255-22-1 (1988), ANSI/IEEE C37.90.1 (1989) Fast transient test 2/4 kV, Cl. 4 EN 61000-4-4 (1995), IEC 61000-4-4 (1995) Numerical Generator Protection REG216 / REG216 Classic 1MRB520004-Ben Page 27 ABB Switzerland Ltd Power Technology Systems Electrostatic discharge test (ESD) 6/8 kV (10 shots), Cl. 3 EN 61000-4-2 (1996), IEC 61000-4-2 (2001) Immunity to magnetic interference at power system frequencies 300 A/m; 1000 A/m; 50/60 Hz EN 61000-4-8 (1993), IEC 61000-4-8 (1993) Radio frequency interference test (RFI) • 0.15-80 MHz, 80% amplitude modulated 10 V, Cl. 3 • 80-1000 MHz, 80% amplitude modulated 10 V/m, Cl. 3 • 900 MHz, puls modulated 10 V/m, Cl. 3 EN 61000-4-6 (1996), EN 61000-4-6 (1996), EN 61000-4-3 (1996), IEC 61000-4-3 (1996), ENV 50204 (1995) Emission Cl. A EN 61000-6-2 (2001), EN 55011 (1998), CISPR 11 (1990) * Reduced values apply for repeat tests according to IEC publication 255-5, Clauses 6.6 and 8.6. Table 42: Mechanical design Terminals CT and PT circuits 10 mm2, Type Phoenix URTK/S Tripping and signalling circuits 4 mm2, Type Phoenix UKK5-MT KD-P/P (GKOS for 216GD61a) Aux. DC supply and remaining aux. circuits 10 mm2, Type Phoenix UK4 (GKOS for 216GD61a) Cubicle wiring CT and PT circuits directly mounted terminals Aux. DC supply (IK62) 0.5 mm2 Tripping and signalling circuits (IK64) 1 - 1.5 mm2 System cables (IK61) 0.14 mm2 Cubicle design ABB Type RESP (see Data Sheet 1MRB520115-Ben) Cubicle dimensions (w x d x h) 800 x 800 x 2200 mm Total weight (with all aux. relays and units inserted) 200 to 400 kg ABB Switzerland Ltd Numerical Generator Protection Power Technology Systems REG216 / REG216 Classic 1MRB520004-Ben Page 28 Ordering In order to configure the generator protection system type REG216 the ABB-Engineering group needs the information from the Questionnaire 1MRB520026-Ken. When ordering the REG216 version the following has to be stated: • Rated current • Rated voltage • Optocoupler voltage • Quantity of different units (electronic part) and interfaces. 1) 216GW62 Input transformer assembly 2) 216GD61a Interface unit consisting of: 8 tripping relays 16 signalling relays 16 optocouplers 3 cables 216IK61. NOTE: For customizing the REG216 version, please contact an ABB sales representative. Table 43: Subcodes Subcodes Explanation Description Remarks for ordering M- M1 Single system 1*rack 216MB66 consisting of 1*NG6x, 1*EA62, 1*AB61, 1*DB61, 1*VC62a 1*GW62 Code K1*GD61a Code IM- M2 Single system 1*rack 216MB66 consisting of 1*NG6x, 1*EA62, 1*AB61, 2*DB61, 1*VC62a 2*GW62 Code K-/L2*GD61a Code IM- M3 Single system 1*rack 216MB66 consisting of 1*NG6x, 1*EA62, 1*AB61, 1*DB61, 1*VC62a 2*GW62 Code K-/L1*GD61a Code IM- M4 Single system 1*rack 216MB66 consisting of 1*NG6x, 1*EA62, 1*AB61, 2*DB61, 1*VC62a 1*GW62 Code K2*GD61a Code IM- M5 Single system 1*rack 216MB66 consisting of 1*NG6x, 2*EA62, 1*AB61, 2*DB61, 1*VC62a 3*GW62 Code K-/L-/N2*GD61a Code IM- M6 Single system 1*rack 216MB66 consisting of 1*NG6x, 2*EA62, 1*AB61, 2*DB61, 1*VC62a 4*GW62 Code K-/L-/N-/O2*GD61a Code IM- M11 Redundant system 1*rack 216MB68 consisting of 1*NG6x, 1*EA62, 1*AB61, 1*DB61, 1*VC62a per system 2*GW62 Code K-/L- common for both systems 2*GD61a Code IM- M12 Redundant system 1*rack 216MB68 consisting of 1*NG6x, 1*EA62, 1*AB61, 2*DB61, 1*VC62a per system 2*GW62 Code K-/L- common for both systems 4*GD61a Code I- Numerical Generator Protection REG216 / REG216 Classic 1MRB520004-Ben Page 29 ABB Switzerland Ltd Power Technology Systems Subcodes Explanation Description Remarks for ordering M- M13 Redundant system 1*rack 216MB68 consisting of 1*NG6x, 1*EA62, 1*AB61, 1*DB61, 1*VC62a per system 1*GW62 Code K- for system A 1*GW62 Code L- common for both systems 1*GW62 Code N- for system B 2*GD61a Code IM- M14 Redundant system 1*rack 216MB68 consisting of 1*NG6x, 1*EA62, 1*AB61, 2*DB61, 1*VC62a per system 1*GW62 Code K- for system A 1*GW62 Code L- common for both systems 1*GW62 Code N- for system B 4*GD61a Code IM- M15 Redundant system 1*rack 216MB68 consisting of 1*NG6x, 1*EA62, 1*AB61, 1*DB61, 1*VC62a per system 2*GW62 Code K-/L- for system A 2*GW62 Code N-/O- for system B 2*GD61a Code IM- M16 Redundant system 1*rack 216MB68 consisting of 1*NG6x, 1*EA62, 1*AB61, 2*DB61, 1*VC62a per system 2*GW62 Code K-/L- for system A 2*GW62 Code N-/O- for system B 4*GD61a Code IM- M21 Double system 2*racks 216MB66 consisting of 1*NG6x, 1*EA62, 1*AB61, 2*DB61, 1*VC62a per rack 1*GW62 Code K- for system A 1*GW62 Code L- common for both systems 1*GW62 Code N- for system B 4*GD61a Code IM- M22 Double system 2*racks 216MB66 consisting of 1*NG6x, 2*EA62, 1*AB61, 2*DB61, 1*VC62a per rack 1*GW62 Code K- for system A 2*GW62 Code L-/N- common for both systems 1*GW62 Code O- for system B 4*GD61a Code IM- M23 Double system 2*racks 216MB66 consisting of 1*NG6x, 2*EA62, 1*AB61, 2*DB61, 1*VC62a per rack 4*GW62 Code K-/L-/N-/O- common for both systems 4*GD61a Code IM- M24 Double system 2*racks 216MB66 consisting of 1*NG6x, 2*EA62, 1*AB61, 2*DB61, 1*VC62a per rack 1*GW62 Code K- for system A 3*GW62 Code L-/N-/O- common for both systems 1*GW62 Code P- for system B 4*GD61a Code IM- M25 Double system 2*racks 216MB66 consisting of 1*NG6x, 2*EA62, 1
