Help CenterModule Spare Parts 5466-409 70653-70070653-095
Related Products
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
| 5466-409 70653-70070653-095 |
Fig. 1 Configuration of the REG216 protection system Excellent electromagnetic compatibility has been achieved through careful attention to physical separation of the interfaces from the signal processing units All hardware can be accommodated in one cubicle, which provides a further screen against induced interference and affords physical protection against dust, etc. REG216 has 17 pre-defined rack configurations with a limited number of I/Os but equipped with the same SW library as the Classic system. Other protection relays for functions which are not part of the REG216 may be installed in the cubicle and correspondingly interwired with REG216. Interfaces to the primary system The following modular assemblies provide interfacing of REG216 to the power system. Input transformer assembly 216GW62 This assembly adjusts the signal levels and provides isolation between the primary system CT and PT circuits and the electronic circuits of the protection. One type of PT and two types of CTs are available, to meet different accuracy and dynamic performance requirements. Space is available for up to 12 transformers, which are selected to suit the application. Up to four assemblies can be used, i.e. 48 inputs. Auxiliary relay and optocoupler assembly 216GD61a This assembly is used in the version of REG216. It provides eight tripping relays, each with powerful, potential-free tripping contacts (with surge circuits), 16 auxiliary relays and 16 optocoupler input circuits. Max. four assemblies can be provided. Input auxiliary relay assembly 216GE61 Up to 16 auxiliary relays can be accommodated, providing complete potential separation of digital input signals. Output auxiliary relay assembly 216GA61 Up to 16 auxiliary relays can be accommodated providing complete potential separation of digital output signals (two contacts per signal). Tripping auxiliary relay assembly 216GA62 Up to eight powerful, potential-free tripping contacts and circuits, which provide highspeed operation (surge circuit) with reduced consumption after operation (economy circuit) are provided. The tripping auxiliary relay assembly can be optionally fitted with a tripping logic diode matrix to enable direct coupling of external signals. REG216 can also read and process external signals via digital inputs
Send Inquiry to This Supplier
