Help CenterPP875 3BSE092977R1 ABB Control Panel Touch Screen Display Panel 800
Related Products
-
PP877K 3BSE069274R1 ABB Man Machine Touch Screen Operation ScreenUS$ 165 - 600MOQ: 100 Pounds -
PP881 3BSF092978R1 PP885 3BSE069276R1 ABB Touch Screen Panel DCS SystemUS$ 100 - 200MOQ: 100 Pounds
-
PPA322B HIEE300016R2 HIEE400235R1 ABB DCS / PLC System ModuleUS$ 165 - 260MOQ: 100 Pounds
-
PPC322BE HIEE300900R1 Control Card Module (supplied by ABB)US$ 100 - 200MOQ: 100 Pounds
-
PPC380AE01 HIEE300885R0001 ABB Inverter Module Board in StockUS$ 113 - 166MOQ: 100 Pounds
PP875 3BSE092977R1 ABB Control panel touch screen display panel 800
PP875 3BSE092977R1 ABB Control panel touch screen display panel 800
Our Email: 2235954483@qq.com
contact number:13313705507
contacts：HE
S800 I/O units are connected to the two CPUs via the optical ModuleBus and two
TB840 cluster modems on each S800 I/O cluster (see Figure 60 on page 169). The
built-in electrical ModuleBus on the TP830 baseplate cannot be used for connecting
S800 I/O in a redundant system.
PM891 Redundancy
The Redundancy Link in PM891 consists of two physical links. These are the
RCU Data Link and the RCU Control Link.
The RCU Data Link is a fast communication channel used to transfer the data
required to keep the backup CPU synchronized with the primary CPU.
TK855 RCU Data Link Cable is used for the data link.
The RCU Control Link is used for role selection and CPU identity assignment
(UPPER/LOWER).
TK856 RCU Control Link Cable is used for the control link.
Fault Tolerance Principle
The principle of fault tolerance in the redundant processor units is based on
continuous updating of the backup unit to the same status as the primary unit. This
enables the backup unit to assume control without affecting surrounding systems in
a bumpless manner.
This principle involves dynamic division of the program execution into execution
units and the creation of rollback points at which the processor unit's status is
completely defined.
In this context, the processor unit's total status is defined as the processor unit's
internal status, that is, the contents of the processor registers, plus the contents of the
data memory.
The backup unit's status is updated each time the primary unit passes a rollback
point, enabling the backup unit to resume program execution from the last rollback
point passed, should the primary unit fail due to error.
In order to minimize the amount of information involved in the update, the backup
unit is updated only with the changes taking place since the latest rollback point.
Send Inquiry to This Supplier
