PP877K 3BSE069274R1 ABB Man Machine Touch Screen Operation Screen

PP877K 3BSE069274R1 ABB Man machine touch screen operation screen

PP877K 3BSE069274R1 ABB Man machine touch screen operation screen

Our Email: 2235954483@qq.com

contact number:13313705507

contacts：HE

Between rollback points, these changes that writes in the data memory, are stored in

a log buffer in the backup unit. At a rollback point, the processor's total register

contents are also written into the data memory, so that this information is also

logged. Once the rollback point is established, the logged write operations are

transferred to the backup unit's data memory.

If the primary unit fails because of an error, the backup unit resumes execution from

the last rollback point, which means the last execution unit is partially re-executed

by the backup unit. In order to re-execute a portion of the execution unit without

affecting the peripheral units (communication units on the CEX-Bus), the peripheral

units' references are also logged between rollback points. During re-execution, the

results of the peripheral units' references, which have already been executed, are

used, rather than re-executing them. The results of read operations are retrieved

from the log, and write operations pass without execution, since they have already

been executed. The peripheral units' statuses, then, are not affected by the reexecution in any way, except for the time delay which occurs.

The RAM included in the processor unit provides an automatic double inverted

memory function for detection of arbitrary bit errors in the memory.

• All memory updates are written to both the primary memory and to the inverted

memory in parallel.

• At every memory read cycle, the data from tho two memories is compared.

• If there is a mismatch in the data a changeover is forced.

The double inverted memory handling is done in hardware and without any delay to

the memory cycle time.
