Help CenterModule Spare Parts PXI-4351 185450D-01
Related Products
-
Module Spare Parts PXI-4461 186900T-11LUS$ 1 - 100000MOQ: 1 Piece -
Module Spare Parts PXI-4462 188261H-11LUS$ 1 - 100000MOQ: 1 Piece
-
Module Spare Parts PXI-6527 185633D-01US$ 1 - 100000MOQ: 1 Piece
-
Module Spare Parts PXI-6608 185745H-02US$ 1 - 100000MOQ: 1 Piece
-
Module Spare Parts SCXI-1001US$ 1 - 100000MOQ: 1 Piece
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
| PXI-4351 185450D-01 |
Temperature and voltage loggers ◾ Accuracy – 0.42 °C for J-type thermocouples, 0.03 °C for thermistors, 0.12 °C for RTDs ◾ 16 voltage or 12 thermocouple inputs; up to 60 readings/s ◾ 8 digital I/O lines (TTL) ◾ Autozero and cold-junction compensation Operating Systems ◾ Windows XP/2000/NT ◾ LabVIEW Real-Time Recommended Software ◾ LabVIEW ◾ LabWindows™/CVI ◾ Measurement Studio Driver Software (included) ◾ NI-435x instrument driver ◾ Traditional NI-DAQ (Legacy) Family Bus Voltage/ (Thermocouple) Channels RTD Accuracy (°C) Thermistor Accuracy (°C) Resistance Measurement NI 4351 PCI, PXI 16/(14) 0.12 0.03 Excellent Table 1. High-Precision DAQ Selection Guide Overview The NI PCI-4351 and PXI-4351 are precision computer-based digitizers designed specifically for high-accuracy temperature measurements (thermocouples, RTDs, thermistors), resistance measurements, chromatography measurements, and low-frequency analog signal measurements within ±15 V. Available for PCI and PXI/CompactPCI, these devices feature ±0.42 °C, J-type thermocouple accuracy; ±0.12 °C RTD accuracy; ±0.03 °C thermistor accuracy; 5½-digit voltage measurements; power line noise rejection filters; and precision current source for RTD and thermistor excitation. NI 4351 devices combine the functionality of stand-alone temperature and voltage meters and chromatographs with the flexibility and benefits of your computer, so you can build highly capable computer-based data-logging systems. As with all computer-based digitizers, NI 4351 devices can easily integrate into your Internet-based applications. Hardware Precision Analog Input NI 4351 devices have 16 differential analog inputs. Each device has a 24-bit analog-to-digital converter (ADC) and six possible reading rates – 10, 50, and 60 readings/s in single-channel acquisition mode and 2.8, 8.8, and 9.7 total readings/s in multiple-channel acquisition mode. For channel speed, divide the total readings/s by the number of channels acquired. Digital filters automatically reject 50, 60, and 400 Hz noise, based on the reading rate. The input circuitry delivers ±42 V overvoltage protection and per-channel lowpass, antialiasing filters. An NI 4351 device features software-selectable ground referencing on a channel-by-channel basis, so you can measure both floating and groundreferenced signals together; it also features per-channel open-thermocouple detection. When open-thermocouple detection is enabled, the input channel is connected to +2.5 VDC through a 10 MΩ resistor. When a thermocouple breaks or is disconnected, the reading rapidly increases to 100 mV or more, indicating an open-circuit condition. Precision Current Excitation These devices feature a 25 μA precision current source for excitation of RTDs, thermistors, or other resistive devices. The source excites the total system resistance of up to 600 kΩ. An NI 4351 also features an additional 1 mA precision current source for RTDs or other resistive devices for total system resistance of up to 15 kΩ. Digital I/O and Alarm Outputs An NI 4351 has eight 5 V/TTL digital lines. You can individually configure each line as an input or an output. You can use the lines as general-purpose digital I/O or as control lines for alarms. Each line sinks or sources 8 mA. With the TBX-68T or CB-68T, you can increase the sinking and sourcing capability of these digital lines to 64 and 15 mA, respectively. With digital signal conditioning accessories, such as the ER-8, SSR Series, and the SC-206x, you can use an NI 4351 to control relays and drive optically isolated digital I/
Send Inquiry to This Supplier
