MSW trommel has always been the bottleneck of waste treatment skills. Whether it is incineration, landfill or comprehensive treatment, there are many failure cases due to incomplete classification of waste, which makes the next process unable to process and the entire production line cannot operate normally.
The domestic dirt is transported into the dirt truck, after weighing, the dirt truck enters the turning workshop of the dirt truck, the dirt is discharged in the dirt temporary storage room, and the deodorant is sprayed at the same time. The materials are sent to the uniform feeder by the bridge-type double beam grab crane, and sent from the uniform feeder to MSW trommel screen. This machine can separate the whole large dirt, 90% of the sand and soil in the dirt, 25-35% of the reusable dirt, and 90% of the big bag of dirt can be broken by bag opening system. The remaining part can be processed by a bag crusher. This machine can fully open the entire unopened bag of dirt in the dirt, disperse the debris sticking to the plastic, and crush objects with a particle size greater than 600mm to less than 60mm Of recyclables.
Heavy duty trommel screen recycling waste specifications:
|
|
|
|
|
Model |
Drum size(m) |
Drum inclination (°) |
Drum speed (r/min) |
Mesh size(mm) |
Max feeding size(mm) |
capacity(m³/h) |
Motor power (kw) |
|
GTS820 |
Φ0.8×2 |
6-10 |
32 |
2-20 |
Mesh size×2.5 |
7-30 |
3 |
|
GTS830 |
Φ0.83 |
6-10 |
32 |
2-20 |
Mesh size×2.5 |
8-50 |
3 |
|
GTS1020 |
Φ1×2 |
6-10 |
25 |
2-20 |
Mesh size×2.5 |
10-60 |
4 |
|
GTS1030 |
Φ1×3 |
6-10 |
25 |
2-20 |
Mesh size×2.5 |
11-80 |
4 |
|
GTS1230 |
Φ1.2×2 |
6-10 |
20 |
2-20 |
Mesh size×2.5 |
12-100 |
5.5 |
|
GTS1240 |
Φ1.2×4 |
6-10 |
20 |
2-20 |
Mesh size×2.5 |
14-120 |
5.5 |
|
GTS1530 |
Φ1.5×3 |
6-10 |
17 |
2-20 |
Mesh size×2.5 |
16-120 |
5.5 |
|
GTS1540 |
Φ1.5×4 |
6-10 |
17 |
2-20 |
Mesh size×2.5 |
18-150 |
7.5 |
|
GTS1550 |
Φ1.5×5 |
6-10 |
17 |
2-20 |
Mesh size×2.5 |
20-180 |
11 |
|
GTS1560 |
Φ1.5×6 |
6-10 |
17 |
2-20 |
Mesh size×2.5 |
22-200 |
11 |
|
GTS1850 |
Φ1.8×5 |
6-10 |
14 |
2-20 |
Mesh size×2.5 |
24-220 |
15 |
|
GTS1860 |
Φ1.8×6 |
6-10 |
14 |
2-20 |
Mesh size×2.5 |
26-240 |
15 |
|
GTS2050 |
Φ2×5 |
6-10 |
12 |
2-20 |
Mesh size×2.5 |
50-600 |
22 |
|
GTS2080 |
Φ2×8 |
6-10 |
12 |
2-20 |
Mesh size×2.5 |
80-700 |
22 |
|
GTS2260 |
Φ2.2×6 |
6-10 |
10 |
2-20 |
Mesh size×2.5 |
100-800 |
30 |
|
GTS2280 |
Φ2.2×8 |
6-10 |
10 |
2-20 |
Mesh size×2.5 |
120-850 |
30 |
if you need more photos and video , please click here to contact me :
if you need more photos and video , please click here to contact me :
Question 1: Can you give me a solution and quotation?
Answer: Absolutely sure, we can provide accurate solution and quotation, please give us background information, including, raw material, the capacity, max. input size, the output size, the usage of final products, etc.
Question 2: Way of payment
Answer: Welcome clients place the order by alibaba online one-touch! Deya also offers various ways of payment, T/T, against copy of B/L, L/C, D/A, D/P, West union, etc. All can be negotiated.
Question 3: What’s the delivery time after I pay the deposit ?
Answer: Normal delivery time within 10 to 20 working days, complete production line or larger equipment may take longer. Exact delivery shall be confirmed when place the order.
Question 4: After order equipment how do we slove the equipment installing?
Answer: For a small single equipment, we offer you user manual, customer will install and commissioning as operating introduction; For a complete production line, we will send our engineer to your workplace to help you install and commissioning untill machines work normally. Sinolion has several experienced technicians with passports ready to go for installation, when installation service is needed, the client should pay for technicians’ round way air tickets, salary(shall be confirmed before leaving), food and lodging, most importantly to guarantee the technicians’ safety.
Question 5: How long of your machine quality guarantee terms?
Answer: Equipment from Zhengzhou Sinolion Machinery Co., Ltd. with 18 months warranty, can be extended to 24 months as request.
