paraffin wax granulation machine / resin granulator machine
Features
Melting material, through material distributor, drips down to the steel belt which is moving evenly. Under the belt, there are continuous sprayer and cooling device which can cool, solidify and pelletize material on belt as soon as possible. According to material feature and process requirements, outward turning, rotating, reciprocating, gate types are available for your choice. Based on material feature and use requirements, material distributing forms like incontinuous dripping, continuous strip, full-width overflowing are available, and with hemispheric, bar, flake products.
Data information
|
Model |
JXSP-60 |
JXSP-120 |
|
Machine width |
600mm |
1200MM |
|
Machine length |
12000mm |
15000mm |
|
Size of mold |
1.8-2.2 mm |
1.8-2.2mm |
|
Size of products |
4-8mm (adjust) |
4-8mm (adjust) |
|
Product’s shape |
hemispherical |
hemispherical |
|
Capacity |
100-150kg/hour for paraffin |
400kg/h for paraffin |
|
|
200-300kg/hour for resin |
600-800kg/h for resin |
|
|
200-300kg for RD |
600-800kg/h for RD |
|
Motor |
5kw+1.5kw |
5.5+1.5kw |
|
Voltage |
380V,50HZ,3 phaze |
380V,50HZ,3 phaze |
|
Water pump |
pressuer: 0.3mpa water flow: 15-20 m3/h (equipped by user) |
pressuer: 0.4mpa water flow: 30 m3/h (equipped by user) |
Pictures
Finally products
Transporting (usually by sea and railway, if you have any special requirements about tranporting, feel free to contact us)
About our factory
