500-600 kg per Hour Rice Milling Machine Vertical Rice Milling Machine Rice Mill Machine

500-600 kg per Hour Rice Milling Machine Vertical Rice Milling Machine Rice Mill Machine photo-1
500-600 kg per Hour Rice Milling Machine Vertical Rice Milling Machine Rice Mill Machine photo-2
500-600 kg per Hour Rice Milling Machine Vertical Rice Milling Machine Rice Mill Machine photo-3
500-600 kg per Hour Rice Milling Machine Vertical Rice Milling Machine Rice Mill Machine photo-4
500-600 kg per Hour Rice Milling Machine Vertical Rice Milling Machine Rice Mill Machine photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2014
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Rice milling machine



Working procedure of rice milling machine



Paddy firstly enters into the machine through vibrating sieve and magnet device, then passes rubber-roller for hulling. After air blowing and air jetting to the milling room, the paddy finishes the process of husing and milling in succession. Then husk, unripe paddy, and white rice are expelled out of the machine respectively. The dust collector collects the fine chaff.





Features of rice milling machine



The machine adopts all the advantages of other types, and has a comprehensive layout, rational design, compact structure and little noise in operation.It is easy to operate with less power consumption and high productivity.

The model can produce white rice with high purity above national standard. The finished rice contains less chaff and low broken rate.So it is indeed a new generation combined rice mill

.



Technical parameter of  rice milling machine



Model

 Capacity (Kg/H)(Paddy)

Power (Kw)

 Overall dimension (mm)

Weight (Kg)

HX-11

 900-1200

 11

760X730X1735

195

HX-12

 900-1200

 12

760X730X1820

230

HX-15

 1100-1500

 15

1070X760X1760

230

HX-16

 1100-1500

 16

1070X760X2000

260

HX-22

 1800-2300

 22

2400X1080X2080

280





Pictures of  rice milling machine



500-600 kg per hour Rice milling machine vertical rice milling machine rice mill machine500-600 kg per hour Rice milling machine vertical rice milling machine rice mill machine



500-600 kg per hour Rice milling machine vertical rice milling machine rice mill machine



500-600 kg per hour Rice milling machine vertical rice milling machine rice mill machine



500-600 kg per hour Rice milling machine vertical rice milling machine rice mill machine

500-600 kg per hour Rice milling machine vertical rice milling machine rice mill machine500-600 kg per hour Rice milling machine vertical rice milling machine rice mill machine500-600 kg per hour Rice milling machine vertical rice milling machine rice mill machine500-600 kg per hour Rice milling machine vertical rice milling machine rice mill machine
