Hot Chamber Die Casting Machine
- 100 Set / Sets per Month
- shenzhen
- T/T
- 25 days
Product Details
Brand Name: | Ruida | Place of Origin: | China | Model Number: | RDC88 |
Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas | Warranty: | 1 year |
Weight: | 3.6 | Dimension(L*W*H): | 3.95×1.38×1.9 | Condition: | New |
Voltage: | 380V, 3ph | Power(W): | 11 |
Product Description
Hot Chamber Die Casting Machine RDH88F
Hydraulic Part
Hydraulic components of famous brands.
Specially-designed squeezing and injection system and a piston-type power accumulator ensure the high speed and strong force of injection.
Injection Part
Nozzle,plunger, steel piston ring and goose neck are made of steel materials of famous brands to ensure long-term stable performance in high temperature and pressure.
Diesel,electrical heating and coke melting method are optional.
Electrical heating at nozzle and goose neck ensures stable temperature for a long time.
The high-quality and durable combustion engine has excellent performance and high reliability.
The specially-designed crossbeam and piston-type power accumulator ensure efficient, stable and safe material stamping.
Item | Unit | RD88T | ||
Die Locking Force | KN | 880 | ||
Die Stroke | MM | 250 | ||
Ejection Fore | KN | 52 | ||
Ejection Stroke | MM | 60 | ||
Die Thickness(Min~Max) | MM | 100-350 | ||
Die Dimension | MM | 535×578 | ||
Tie-bar Inner Spacing(V×H) | MM | 357×357 | ||
Tie Bar Diameter | MM | 63 | ||
Injection Port Position | MM | 0,-60 | ||
Injection Stroke | MM | 130 | ||
Traverse Stroke | MM | 190 | ||
Injection Fore | KN | 90 | ||
Plunger Tip Diameter | MM | 50 | 55 | |
Specific Pressure | Mpa | 34 | 28.1 | |
Shot weigh(Zn) | kg(Zn) | 1.26 | 1.53 | |
Hydraulic Pressure | Mpa | 10.5 | ||
Electric Motor Capacity | KW | 11 | ||
Volume of Crucible(Zn) | L/kg(Zn) | 55/360 | ||
Volume of Oil | L | 240 | ||
Machine Weight | TON | 3.6 | ||
Over All Dimensions | m(L×W×H) | 3.95×1.38×1.9 |
