Soy Sauce Production Line/soy Sauce Sterilizer

 Our Factory manufacture industrial

Pasteurizer for milk, yogurt, ice cream, juice and other beverage

UHT sterilizer, continuously sterilization machinefor dairy liquid, juice , wine, pharmacy liquid, and other food liquid like sauce

Machine name and capacity

Milk Pasteurizer

Milk pasteurizer 100Litres, 200Litres, 300Litres, 400Litres, 500Litres, 600Litres, 800Litres, 1000Litres,1200Litresper hour pasteurizer

and other capacity pasteurizer according to clients requirement

Heating Source

Steam heating, Electric heating , natural gas heating

Model

Capacity

(T/H)

Heat

Exchange Area (M2)

Gross

Power(KW)

Steam Consumption

(Kgs/hour)

Overall

Dimension(mm)

Total

Weight

Ucan-PHE-0.5

0.5

5

5.2

52

1200×1200×1500

790kg

Ucan-PHE -1

1

8

5.2

60

1500×1500×1800

880kg

Ucan-PHE -2

2t/h

13

6

104

1800×2000×1800

980kg

Ucan-PHE -3

3t/h

20

6

156

2000×2000×2200

1080kg

Ucan-PHE -5

4-5t/h

30-45

8

260

2250×2000×2200

1250kg

Ucan-PHE -8

6-8t/h

35-50

8

400

2250×2000×2200

1250kg

Ucan-PHE-9

10t/h

60-

11

520

2800×2000×2200

1650kg

Ucan-PHE-15

15t/h

75

15

780

3000×2200×2200

2150kg

Ucan-PHE-20

20t/h

80

18

945

3300×2200×2200

2350kg

Function and Feature

1.    Electric heating pasteurizer  integrates

multi-functions:

such cooling, heating , pasteurizing ,temperature keeping and controlling, , in short time and very easy to operate

2.    The material and the heating medium are in their own sealing system, ensure milk or other juice liquid materials sanitary and clean

3.      Pasteurization temperature and time could be controlled and adjusted easily by users, good pasteurization effect and milk, juice nutrition can be kept.

4.      Good heat transfer effect, high heat recovery, less energy consumption;

5.      Simple structure, easy to clean, convenient operation, low noise, low cost of maintenance and running life more than 10years.

6.Could be connected to CIP cleaning system or can be cleaned manually

Package

Plywood box, standard for exporting and protect goods safely deliverying
