Help CenterFineness Gauges Grindometer Fineness of Grind Gauge
Related Products
STANDARDS: ASTM D 333, D 1210, D 1316; ISO 1524; FTMS 141a
Grind gages are used in controlling the production, storage and application of dispersion products produced by milling in the paint, plastic pigment, printing ink, paper, ceramic, pharmaceutical, food and many other industries.
The Fineness of Grind Gage is a flat steel block in the surface of which are two flat-bottomed grooves varying uniformly in depth from a maximum at one end of the block to zero near the other end. Groove depth is graduated on the block according to one or more scales used for measuring particle size.
We offer a wide variety of grind gages varying in scales, number of grooves, length and width of grooves and size of the block.
Comes in a reusable box to prevent damage.
|
Cat.No |
Dims(mm) |
Path Width(mm) |
No.of Paths |
Range (um) |
Range (Hegman) |
Range (MILS) |
|
JR-2400 |
120×25×13 |
12 |
1 |
0-15 |
-- |
-- |
|
JR-2401 |
120×25×13 |
12 |
1 |
0-25 |
-- |
-- |
|
JR-2402 |
165×37×12 |
12 |
2 |
0-15 |
-- |
-- |
|
JR-2410 |
170×50×15 |
12 |
1 |
0-15 |
-- |
-- |
|
JR-2411 |
175×65×15 |
14 |
1 |
0-25 |
8-6 |
-- |
|
JR-2412 |
175×65×15 |
14 |
1 |
0-50 |
8-4 |
-- |
|
JR-2413 |
175×65×15 |
14 |
1 |
0-100 |
8-0 |
-- |
|
JR-2414 |
170×50×15 |
12 |
1 |
0-150 |
-- |
-- |
|
JR-2420 |
175×65×15 |
12 |
2 |
0-25 |
8-6 |
0-1 |
|
JR-2421 |
175×65×15 |
12 |
2 |
0-50 |
8-4 |
0-2 |
|
JR-2422 |
175×65×15 |
12 |
2 |
0-100 |
8-0 |
0-4 |
|
JR-2430 |
175×65×15 |
37 |
1 |
0-15 |
-- |
-- |
|
JR-2431 |
175×65×15 |
37 |
1 |
0-25 |
8-6 |
0-1 |
|
JR-2432 |
175×65×15 |
37 |
1 |
0-50 |
8-4 |
0-2 |
|
JR-2433 |
175×65×15 |
37 |
1 |
0-100 |
8-0 |
0-4 |
|
JR-2440 |
240×85×25 |
25 |
2 |
0-25 |
-- |
-- |
|
JR-2441 |
240×85×25 |
25 |
2 |
0-50 |
-- |
-- |
|
JR-2442 |
240×85×25 |
25 |
2 |
0-100 |
-- |
-- |
Comes Complete with:
Grind Block
Scraper
Application Manual
Reusable Storage Case
