Name:WSC-1B lab portable colorimeter diamond colorimeter with Small measuring aperture
Type:WSC-1B
Characteristics
The instrument fully considered the user experience. Adopting humanized design concept – make the measurement easier.
Adopting creative facula locating and cross locating – make the measurement conveniently, quickly and accurately.
Small measuring aperture – easy to measure concave – convex object.
No need to calibrate each time which simplify the operation
New integrating sphere optical path design – improve measurement stability and precision.
This colorimeter has various spaces. The user can select it according to their needs. And the instrument can display Whiteness, Yellowness and Color Fastness which is used widely.
The precise and stable hand – head structure t make the measurement easier.
Specifications
|
Display Mode |
CIEL*a*b*C*h*;CIEL*a*b; CIE XYZ |
|
Color Difference Formula |
E*ab;L*a*b; E*C*h |
|
Illuminating/Viewing geometry |
8/d |
|
Light source |
LED blue light excitation |
|
Detector |
Silicon photoelectric diode |
|
Measuring Aperture |
Φ4mm |
|
Measuring Conditions |
D65 |
|
Repeatability |
Standard deviation within E*ab 0.08(Measurement conditions: Average of 30 measurements of standard white plate) |
|
Storage |
100 pcs standard samples;20000 pcs test samples |
|
Minimum Interval Between Measurement |
Approx. 1 sec |
|
Battery Life |
More than 3000 times |
|
Lamp Life |
3 years, more than 1.6 million times |
|
Display |
TFT ture color 2.8inch@(16:9) |
|
Interface |
USB RS232 |
|
Operating Temperature Range |
-10 – 40℃(32 – 104℉) |
|
Storage Temperature |
-20 – 50℃(-4 – 122℉) |
|
Humidity Range |
Relative humidity 0 – 85% with no condensation |
|
Weight |
450g |
|
Dimensions |
205mm 67mm 80mm |
|
Standard Accessories |
Powder adapter, Li-ion Battery, operating instruction, white calibration cover, wristband, cross platform, 4mm measuring aperture, software, USB cable, 4mm aperture for small concave-convex surface |
|
Operation Accessories |
Miniature thermal printer |
