All materials in contact with the product use inert materials to meet the requirements of the GLP.
The cold trap and console are made of stainless steel, which is anti-corrosion and easy to clean.
All stainless steel inflflated /water release valve is designed and produced by our company, which is safety, anti-corrosion, no leakage.
With sample pre-frozen function, large cold trap opening, no inner coil, and low temperature refrigerator is needless.
Patented gas diversion technology, and strong ice holding ability.
World- known brand compressors, high effificiency, long life, low noise.
Well-known brand vacuum pump with a high pumping speed to achieve a higher ultimate vacuum.
Vacuum pump protection function can set the cold trap temperature to protect the vacuum pump life.
Professionally designed FD-LAB freeze-drying machine control system + SH-HPSC-I modular controller with high reliability and stability.
Intelligent data recording system can real-time record and display the cold trap temperature curve, sample temperature curve,vacuum curve.
Model | BNFD-L18S | BNFD-L27S | BNFD-L18ST | BNFD-L18M | BNFD-L27M | BNFD-L18MT | |||||
Freeze drying area | 0.18㎡ | 0.27㎡ | 0.09㎡ | 0.18㎡ | 0.27㎡ | 0.09㎡ | |||||
Tray diameter | Ф240mm | Ф240mm | Ф200mm | Ф240mm | Ф240mm | Ф200mm | |||||
Quantity. of tray | 4pcs | 6pcs | 3pcs | 4pcs | 6pcs | 3pcs | |||||
Tray spacing | 70mm | ||||||||||
Cold trap temperature | ≤-56℃,optional≤-80℃ | ||||||||||
Cold trap depth | 400mm | ||||||||||
Cold trap diameter | Ф270mm | ||||||||||
Ice collecting capacity | 6kg/24h | ||||||||||
Pumping speed | 4L/S | ||||||||||
Ultimate vacuum | ≤5pa | ||||||||||
Power | 1400w | ||||||||||
Net weight | 105kg | ||||||||||
-56℃ Overall dimensions | 630×580×970mm | ||||||||||
-80℃ Overall dimensions | 810×580×950mm | ||||||||||
Drying chamber size | Ф300×445mm | Ф300×445mm | Ф300×540mm | Ф300×465mm | Ф300×465mm | φ300×570mm | |||||
Cooling mode | wind cooled | ||||||||||
Defrosting mode | air cooled | ||||||||||
Material capacity | 1.8L(thickness 10mm | 2.7L(thickness 10mm | 0.9L(thickness 10mm) | 1.8L(thickness 10mm | 2.7L(thickness 10mm | 0.9L(thickness 10mm) | |||||
Vials loaded quantity | / | / | 615pcs of Ф12mm | / | / | 615pcs of Ф12mm | |||||
/ | / | 345pcs of Ф16mm | / | / | 345pcs of Ф16mm | ||||||
/ | / | 183pcs of Ф22mm | / | / | 183pcs of Ф22mm | ||||||
Flask capacity & quantity | / | / | / | 100/250/500/1000ml,each 2pcs | |||||||
