Products Description
Fast photosynthetic testing Plant Photosynthesis Meter
The plant photosynthesis meter can measure CO2 concentration, leaf temperature, photosynthetically active radiation, and leaf temperature humidity. Through scientific calculation, the photosynthesis rate such as leaf photosynthetic rate, leaf transpiration rate, intercellular CO2 concentration, stomatal conductance, and water utilization rate can be obtained. index.
Features:
The plant photosynthesis meter can measure CO2 concentration, leaf temperature, photosynthetically active radiation, and leaf temperature humidity. Through scientific calculation, the photosynthesis rate such as leaf photosynthetic rate, leaf transpiration rate, intercellular CO2 concentration, stomatal conductance, and water utilization rate can be obtained. index.
Features:
1. The shape is small and light, easy to carry around, measure anytime and anywhere, and can be operated by a single
person.
person.
2. The dot matrix LCD screen is 320*240, the English menu displays multiple information, and the cursor guides the
operation.
operation.
3. Open-circuit measurement and closed-circuit measurement are available, electronic flowmeter.
4. The key switch, the data cable and the trachea interface are moved to the front panel, which is more convenient to use. 5. The modification date, time, leaf area, volume, measurement interval, user name, etc. can be set.
6. The measurement process and final results are displayed and stored in time. Historical data can also be viewed on the instrument.
7. The data stored in the host can be imported into the computer for secondary analysis and can be printed.
8. Automatically display air carbon dioxide concentration, air humidity, relative humidity, light and effective radiation intensity, temperature and leaf temperature.
9. Various types of leaf chambers (reactors) are suitable for different measurement objects such as various plant leaves, seeds, insects, etc.
More Details
Specification
Product name | Plant photosynthesis meter | |
Model | 3051C | |
Host parameters: | ||
Working environment | temperature 0 ℃-50 ℃, relative humidity: 0-100% (no water vapor condensation) | |
Power supply | DC8.4V lithium battery, can work continuously for 7-9 hours | |
Data storage | 2GB SD card, which can store 500,000 sets of data for a long time. Text document format, no need to configure communication software | |
Size | 260×260×130mm | |
Weight | 3.5kg | |
CO2 Analysis | Non-Diffusion Infrared CO2 Analysis | |
Measuring range | 0~1000ppm/0~1500ppm/0~2000ppm; Resolution: 0.1ppm; Accuracy: 0.1ppm | |
Leaf chamber temperature | imported high-precision digital temperature sensor | |
Measuring range | 0~50℃; Resolution: 0.1℃; Error: ±0.2℃ | |
Leaf temperature test | platinum resistance | |
Measuring range | 0~50℃; Resolution: 0.1℃; Error: ±0.2℃ | |
Leaf humidity | high-precision digital humidity sensor imported from Switzerland | |
Measuring range | 0~100%, resolution: 0.1%, error: ≤±3% | |
Photosynthetically Active Radiation (PAR) | Silicon Photovoltaic Cells with Corrective Filters | |
Measuring range | 0-2500μmolm㎡/s; Accuracy: ≤5μmolm㎡/s | |
3 leaf chamber sizes | the standard size is 55×20mm, other sizes can be customized according to customer needsType I: (20×25mm) Type II: (55×20mm) Type III: (65×10mm) | |
Optional accessories | Leaf chamber: various specifications of leaf chamber, respirator, assimilation box, etc. can be customized according to requirements Light source: red/blue LED light source, adjustable range 0—2000μmolm ㎡/sec | |
