6 Channels Soxhlet Extraction Theory Milk Fat Analyzer
By Soxhlet extraction with weight determination of the basic principles for the determination of food, feed fat content. Set of immersion, extraction, solvent recovery, and drying in one, automatic temperature control, there is no leakage of waste, recyclable reagents, low-cost, high degree of automation.
Trait:
1. Closed electric heating, room temperature ~ 200 ℃ any adjustment;
2. Blue LCD display, displays set and actual temperature, holding time countdown and remind;
3. Automatic collect of solvent and storage;
4. No plug design: no leaks and improve the life;
5. limit temperature protection
6. Intelligent: 6 stages can be set to the temperature and holding time, it will accord sequence running automatically;.
7. Drying function: no transfer to the oven, directly dry on instrument.
Technical parameters:
1. Measure Range: Crude fat content ≥ 0.5% ;
2. Measure quantity: 6 samples at same time;
3. Solvent reclaim rate ≥ 80%;
4. Precision: Relative difference ≤ 3%, Parallel difference ≤ 0.3%;
5. Solvent collection methods: automatically collect and store;
6. Reclaim rate: ≥ 99% (backflow Speed 120 drop/minute, Cooling water temperature ≤ 30℃);
7. Heating: Aluminum Alloy plate, electric heating;
8. Seals: PTFE seal;
9. Display: blue screen LCD; holding time countdown;
10. Other features: 6 stages of heating, drying
11. Temperature control range: Room temperature~200℃;
12. Temperature control precision: ±0.3℃;
14. Rated power: 500W;
Model difference
| Model | NZF-06A | NZF-06B | NZF-06C | NZF-06 |
| Measuring range | 0.5%~60% content of food,feed,oil products | |||
| Max sample test | 6 | |||
| Power supply | 220V,50HZ | |||
| Heating unit | Water bath | Electronic heating board | ||
| Heating power | 800W | 300W,500W | ||
| Temperature rising time | 10min | |||
| Recovery | automatic | semi-auto | automatic | automatic |
| Solvent recovery | ≥80% | |||
| Temperature control | +5C-90℃ | +5C-200℃ | ||
| Dimension | 740*230*655mm | 740*200*585mm | 570*330*655mm | 570*330*655mm |
| Weight | 23kg | 20kg | 23kg | 23kg |
| Difference | heating uniform,auto recovery | heating uniform,semi-auto recovery | heating uniform,auto recovery,including soaking and extraction process,save working time | electronic board heating,heating uniform,auto recovery,including soaking and extraction process,save working time |
Series products of Fat analyzer
| Kjeldahl protein analyzer | Crude fiber analyzer | ||
| |
|
||
Package : Wooden case
Shipping : 5~7days after payment
Pre-sale service
² 24hours online to ensure quick response to customers' inquiry or online message;
² Guide customers to choose the best suitable machine model;
² Offer detailed specification and competitive prices;
Contract execution
² Machine production will be arranged strictly according to the contract;
² Machine photos will be sent to you for inspection during production;
² Send customs clearance documents by DHL;
² Update latest news after delivery and prepare customs clearance;
After-sale service
² 12 months warranty except for wear parts;
² Broken spare parts (except for wear parts) will be sent for free due to quality problems;
² In time response to customers technical problems;
² New products update for customers' reference
1. How can I choose the suitable one?
Dear customer, please tell us your detailed requirements by mail or online, we will recommend the suitable one as your request.
2. How can I pay?
Dear customer, we accept many payment term, such as T/T, Western Union…
3. When I receive it after pay?
Dear customer, normal models can be delivered with 5-7days, please contact us to check transport time to your address.
4. How to deliver?
Dear customer, we can send by Express, by Sea and by Air.
5. Is will be broken during transport?
Dear customer, please do not worry, we do standard export package. If product broken during transportation,we will replace you new.
6. What should I do if I do not know how to use?
Dear customer, please do not worry, manual user will be sent together, our techincal engineer also can supply phone,vedio guidance. If need,we will supply oversea service on site.
7. What should I do if some parts broken?
Dear customer, please do not worry, we have 12months warranty and whole life maintenance.
