hb electrophoresis with multiple models and reliable quality
Model: DYCP – 40C
Features:
1. Special design and select material;
2. Easy and simple for the end user to use;
3. Minimum buffer solution, with no need for mess and additional accessories;
4. Fast transferring speed and good transferring effect;
5. Safe plug technique, all the exposed parts are insulated;
6. The transferring bands are very clear;
Specifications:
1. Transferring dimensions: 150 x 150 (mm);
2. Max. input voltage: 600V; Max. Current: 200mA;
3. Continuous working time: ≥24 hours;
4. Size (L X W X H): 210 × 186 × 100 (mm);
5. Weight: about 3 kg
Applications:
For fast transferring the protein molecule from the gel to membrane like Nitrocellulose membrane *
* Our Nitrocellulose membrane (Cat. No.: 241 - 0005): 150 x 150 (mm)
Suitable Electrophoresis Power Supply
DYY – 7C
Parameters:
|
Model |
Gel dimension (L×W)mm |
Samples |
Comb thickness (mm) |
Buffer volume (mL) |
Size (L×W×H) mm |
Weight (Kg) |
|
DYCZ-24EN |
130×100 |
12;16 |
1.0;1.5 |
1200 |
190×120×170 |
2.0 |
|
DYCZ-30C |
105×185 |
25;40;52 |
1.0;1.5 |
1800 |
250×160×158 |
1.8 |
|
DYCP-38C |
60/100×240 |
— |
— |
1000 |
370×270×110 |
2.0 |
|
DYCP-43 |
— |
— |
— |
1200 |
231×148×121 |
1.0 |
|
DYCP-43B |
— |
— |
— |
550 |
260×185×73 |
2.0 |
|
DYCP-44P |
170×140 |
33×6 (1.0) ;17×6 (1.5) |
1.0;1.5 |
200 |
210×200×40 |
0.5 |
|
DYCP-44N |
200×100 |
(1+8)×12 |
1.5 |
200 |
260×110×40 |
0.5 |
|
DYCP-35 |
180×160 |
— |
— |
250 |
— |
4.0 |
|
DYCP-32B |
200×130;150×130 |
14 (1.0), 26(1.0),18(1.0,1.5) |
1.0;1.5 |
800 |
360×160×100 |
1.5 |
|
DYCP-32A |
160×100; 80×100 |
12;16;22 |
1.0;2.0 |
650 |
300×162×110 |
2.0 |
|
DYCP-31A |
85×80; 40×80 |
12;15 |
1.0;2.0 |
500 |
242×132×105 |
1.0 |
|
DYCZ-30B |
105×185 |
25;40;52 |
1.0;1.5 |
1400 |
245×115×165 |
3.0 |
|
DYCZ-20D |
300×340 |
64 |
0.4 |
1000 |
505×220×350 |
9.0 |
|
DYCZ-24DN |
83 × 75 |
10;15 |
1.0;1.5;0.75 |
400;170 |
150×100×140 |
1.0 |
|
DYCP-31BN |
60×60 |
6 (1.5); 8(1.5);11 (1.0,1.5) |
1.0;1.5 |
120 |
197 × 96 × 64 |
0.5 |
