Home > Manufacturing & Processing Machinery > Chemical Equipment & Machinery > Chemical Drying Equipment > China Factory Lab Refrigerated Fruit Vegetable Top Press Vacuum Freeze Dryer Machine Price
China Factory Lab Refrigerated Fruit Vegetable Top Press Vacuum Freeze Dryer Machine Price
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2015
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Lab Ophthalmic Equipment Portable Digital Slit LampNegotiableMOQ: 1 -
Remote Control Optics Ophthalmic Equipment Optotype Auto Chart ProjectorNegotiableMOQ: 1
-
NANBEI Biomicroscope Ophthalmic Digital Portable Slit Lamp MicroscopeNegotiableMOQ: 1
-
Automatic Control Laboratory Stainless Steel Electric Water Distiller Apparatus 20L/HourNegotiableMOQ: 1
-
Stereoscopic Microscope Biomicroscope Digital Portable Slit LampNegotiableMOQ: 1
Products
Application:
The laboratory freeze-drying machine is a freeze-drying equipment specially developed by NANBEI for laboratory users. It has a desktop or vertical design, compact structure and small footprint; it is suitable for laboratory placement and installation. It is widely used in biopharmaceutical, medical, food and other industries. For example, in the production of biological products, BCG vaccine, meningococcal vaccine, measles vaccine, influenza vaccine, etc.; Western medicine production of Chinese antibiotics, circulatory organ drugs, etc. In the medical field, freeze-drying technology can be used for long-term preservation of various organs such as blood, arteries, bones, skin, cornea, and nerve tissue. NBFD-10 series laboratory freeze dryer products are divided into basic type, gland type, multi-manifold type, multi-manifold gland type.
Features
1. Imported brand compressors, fast cooling speed and large cooling capacity
2. 7-inch color LCD touch screen design, digital and curve display at the same time sample temperature, cold trap temperature and vacuum degree and other freeze-drying parameters
3. Standard USB interface, with historical data query and storage function
4. The inflation valve can be filled with dry inert gas (optional)
5. Cold trap electric defrost function (optional)
6. Separate electric heating function, can explore the pilot freeze-drying process (optional)
Specification
Model | NBFD-10S (standard) | NBFD-10P (Multi-manifold common type) | NBFD-10T (Gland type) | NBFD-10PT (Multi-manifold gland type) | |||||
Cold trap temperature（℃） | ≤-60 | ||||||||
Vacuum（Pa） | <10 | ||||||||
Freeze-dried area （m2） | 0.12 | 0.09 | |||||||
Water catching capacity（Kg/24h） | 3 | ||||||||
Material loading（ml） | 1200 | 900 | |||||||
Material tray specifications （ф*h mm） | 200*20 | ||||||||
Layers of material tray (layers) | 4 | 3 | |||||||
Material/tray (ml) (Material thickness 10mm) | 300 | ||||||||
Freeze drying time (h) | 24 | ||||||||
Number of external freeze-dried bottles (pieces) | / | 8 | / | 8 | |||||
Vials | (ф22mm) | 260 | 195 | ||||||
(ф16mm) | 480 | 360 | |||||||
(ф12mm) | 920 | 690 | |||||||
Size | （W*D*H）mm | 582*541*374/684 | |||||||
Details Images
Recommend Products
Company Profile
Certifications
FAQ
Q1: Why Choose NANBEI ?
(1).Professional manufacturer with more than 13 years experience
(2).Exported to more than 97% Countries
(3).Turnkey Solution is no problem
Q2:OEM,ODM acceptable or not?
Absolutely Yes
Q3:What's kind of Payment terms for customer choosing?
T/T ,Western Union, Money Gram , Credit Card, Paypal , L/C ...
Q4:Can we visit your factory online?
Absolutely no problem
Q5:Can online video inspection before shipment?
Absolutely no problem
Q6: what's the MOQ ? Sample order is OK?
MOQ:1 set, sample order is no problem
Q7:What's kind of shipment for customer choosing?
Usually ship by sea, by air, by international express .
We can also provide reasonable solutions according to your transportation requirements
Q8:How to ensure product quality and after-sales service?
We have CE, ISO quality certificate, and SGS authentication.
After-sale service:
1.Warranty : 1 year
2.We supply free part for quality problem in warranty
3.Long life technical support and service
