Digital Rotation Paint Heated Rotating Viscometer
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2015
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Portable Plant Photosynthetic AnalyzerNegotiableMOQ: 1 -
Lab Hot Sale Cheap NDJ-8S Digital ViscometerNegotiableMOQ: 1
-
KDN Semi Automatic Kjeldahl Distillation Apparatus Nitrogen AnalyzerNegotiableMOQ: 1
-
Viscosity Measuring Instruments Rotary Digital ViscometerNegotiableMOQ: 1
-
Laboratory Kjeldahl Apparatus Nitrogen Analyzer for Protein AnalysisNegotiableMOQ: 1
Product Description
NDJ-1F Brookfield Rotational Viscometer
Product introduction：
Brookfield rotational viscometer is designed and made according to the requirement of the ASTM D 789, ASTM D 4878 and T0625 “Asphalt Brookfield Rotation Viscosity Test (Brookfield Viscometer Method)” in the Industry Standard of People’s Republic of China JTJ052 Specifications and Test Methods of Bitumen and Bituminous Mixtures for Highway Engineering. It is suitable to determine the absolute viscosity of the Newtonian liquids and the apparent viscosity of the non-Newtonian liquids.
Brookfield rotational viscometer adopts the advanced mechanical design technology, manufacturing techniques and microcomputer technology for temperature control, data collection, and data processing. It takes a white background light, ultra bright LCD screen as display screen. The instrument also equips a pin type micro-printer for data output. The measurement data can be shown on the display screen in real time and printed out through the printer. In addition, the instrument can connect to the PC through the RS232 communication interface.
Brookfield rotational viscometer has the characteristics of high measurement sensitivity, reliable results and delicate shape, as well as convenience to be operated. It can be widely used to determine the viscosity of various liquids such as asphalt, hot sol, paraffin, high polymer and so on.
More Details Photos
Digital display screen
Heater
Temperature controller
Specification
Measurement range |
25 mPa•s～1×107 mPa•s ( If choosing the No.30 spindle, the measurement range can extend to 2×107 mPa•s) |
Spindle: |
No. 21, 27, 28, 29 total four types of spindles (the No.30 is optional) |
Spindle speed: |
0.1～200 RPM, continuously speed regulation (With 12 grades of speed) |
Measurement error |
±1% (F•S), choosing the No.30 spindle, it will be ±3% (F•S) |
Temperature control range: |
45 ℃～200 ℃ |
Temperature control accuracy: |
±0.1 ℃ |
Sample cylinder cubage: |
20 ml |
Power supply: |
AC 220 V±10%, 50 Hz |
Ambient temperature |
5 ℃～35 ℃ (when the control temperature of the heater is close to the ambient temperature, turn on the air conditioner to allow the ambient temperature is approximately 5 ℃ lower than the control temperature of the heater); |
Relative humidity: |
≤80% |
Printing output: |
needle printer |
Comunication port |
RS232 port |
Optional accessories
1.NDJ-1F Brookfield Viscometer and Computer communication software(CD)
2. 300℃ high temperature heating furnace
3. 30# rotator
NDJ-1F Brookfield Viscometer Accessories and Documents List
No. |
Name |
Unit |
Quantity |
1 |
Head of viscometer |
Set |
1 |
2 |
Pedestal of instrument (having three level adjustment bolts) |
Set |
1 |
3 |
Toothed rod |
Piece |
1 |
4 |
Auxiliary controlling case (containing a temperature controller and a micro-printer) |
Set |
1 |
5 |
Heater |
Piece |
1 |
6 |
Spindle (No.21, 27, 28 and 29) |
Piece |
1 for each |
7 |
Connection hook and transition bolt |
Piece |
1 for each |
8 |
Power supply wire (250 V 6 A) |
Piece |
1 |
9 |
Serial port wire |
Piece |
1 |
10 |
Heater connection wire |
Piece |
1 |
11 |
Sensor wire |
Piece |
1 |
12 |
Sample cylinder, sample cylinder holder, sample cylinder cover, special forceps |
Piece |
1 for each |
13 |
Fuse (Φ5×20) 5 A |
Piece |
3 |
14 |
CD for communication with a PC |
Piece |
1 |
Recommendations
Company Profile
Customer Concerns
FAQ
Q1: Why Choose NANBEI ?
(1).Professional manufacturer with more than 13 years experience
(2).Exported to more than 97% Countries
(3).Turnkey Solution is no problem
Q2:OEM,ODM acceptable or not?
Absolutely Yes
Q3:What's kind of Payment terms for customer choosing?
T/T ,Western Union, Money Gram , Credit Card, Paypal , L/C ...
Q4:Can you visit your factory online?
Absolutely no problem
Q5:Can online video inspection before shipment?
Absolutely no problem
Q6: what's the MOQ ? Sample order is OK?
MOQ:1 set, sample order is no problem
Q7:What's kind of shipment for customer choosing?
Usually ship by sea, by air, by international express .
We can also provide reasonable solutions according to your transportation requirements
Q8:How to ensure product quality and after-sales service?
We have CE, ISO quality certificate, and SGS authentication.
After-sale service:
1.Warranty : 1 year
2.We supply free part for quality problem in warranty
3.Long life technical support and service
