Steel Cord Conveyor Belt Steel Cord Rubber Conveyor Belt Rubber Conveyor Belt

HENGTUO Steel cord conveyor belt has high tensile strength, low elongation and good fatigue resistance; Steel cord conveyor belt for general use is widely used in coal, mine, port, metallurgy, power, chemical industries and suitable for high strength, long distance and heavy load transportation of materials. Further, the finish standards these are made available in include EN ISO 15236, DIN22131, SANS1366

Steel Cord Conveyor Belt Construction:

Steel Cords: steel cords at certain arrangement which become the main tension holder of belt. Special High carbon content steel strand cords with special heat treatment, which makes the cord highly resistant to breakage and repeated dynamic stresses as well as highly flexible. Warp cords are galvanized and fully embedded in rubber. Twist cord alternating right and left hand to ensure the belt go straighty.

Rubber Cover: top rubber cover + bottom rubber cover, protect the carcass from abrasion, impact, water and other injurious influ-ence.

Rip Stop or Transverse Reinforcement: one or two steel breaker

(No need for normal usage)

Features and Advantages of Steel Cord Conveyor Belt

●High tensile strength: steel cord conveyor belt is suitable for transferring materials with long distance, high intensity and large load.

●Small elongation in use: a very short take-up stroke distance needed.

●High adhesion between rubber and steel cord : the steel cord are coated with zinc on the surface, highly adhered to the special core rubber to resistant to heavy impact.

●Good troughability: as the belt body has no transverse carcass, it is easy to form a deep trough to load more materials without leak.

●Small diameter of driving pulley: the belt body had a layer of longitudinally arranged steel cords as its carcass to resistant to flex fatigue. Therefore, driving pulley with smaller diameter can be used to reduce energy consumption.

●Even tension of steel cords: thanks to our advanced techniques in manufacturing, the steel cords are evenly arranged with the same tension, so the belts are well balanced in running and difficult to run away.

Applications of Steel Cord Conveyor Belt:

Steel cord conveyor belt for general use is widely used in coal, mine, port, metallurgy, power, chemical industries and suitable for high strength, long distance and heavy load transportation of materials. For more application cases, please click here

HENGTUO is Conveyor Belt Manufacturers in China and Conveyor Parts Supplier. We committed to supply personalized Conveying Systems Solutions to customers, pls consult us.
