Digital Portable Hardness Tester Meter Durometer Leeb hardness Tester for Metal Steel
Application:
1.Die cavity of molds
2.Bearings and other parts
3.Failure analysis of pressure vessel, steam generator and other equipment
4.Heavy work piece
5.The installed machinery and permanently assembled parts
6.Testing surface of a small hollow space
7.Material identification in the warehouse of metallic materials
8.Rapid testing in large range and multi-measuring areas for large-scale work piece.
| Measuring range | HLD (170-960),HRC (17.9-69.5),HB (19-683),HV (80-1042),HS (30.6-102.6),HRA(59.1-88),HRB (13.5-101.7) |
| Impact Directions | Up, down, horizontal, slanting up, slanting down |
| Measuring Materials | Steel and cast steel, alloy tool steel, stainless steel, gray cast iron, nodular cast iron, cast aluminum alloy, copper zinc alloys (brass), an alloy of copper and tin, copper (bronze), forged steel |
| Standards | ASTM A956,DIN50156-1,GB/T17394-1998 |
| Hardness Scales | HL,HB,HRB,HRC,HRA,HV,HS. |
| Tensile Strenght | 374 to 2652 N/m 2 |
| Display | 128*64 digital matrix LCD |
| Memory | 600 groups max.(relative to impact times 32~1) |
| Work Voltage | 9V/500mA |
Main Features
1.Large screen(128×64 dot matrix LCD), showing all functions and parameters.
2.Test at any angle, even upside down.
3.Support "forged steel (Steel)" material, when using the D/DC impact device test "forged" sample, can read HB value directly, without the need for manual checking table.
4.Wide measuring range. It can measure the hardness of all metallic materials. Direct display of hardness scales HRB, HRC, HRA, HV, HB, HS, HL and three types of strength values immediately.
5.Seven impact devices are available for special application. Automatically identify the type of impact devices.
6.Large capacity memory could store 600 groups (Relative to average times32~1 ) information including single measured value, mean value, testing data, impact direction, impact times, material and hardness scale etc.
7.Upper and lower limit can be preset. It will alarm automatically when the result value exceeding the limit.
8.Battery information indicates the rest capacity of the battery and the charge status.
9.User calibration function.
10.USB port with the PC humanity multi-functions data proceeding software.
11.Original imported high speed thermal printer support the immediate printing function. It can save data permanently.
12.NI-MH rechargeable battery as the power source. Charge circuit integrated inside
Iwintesting equipment company is a high-tech enterprise focusing on the research and development, production and sales of engineering quality test and testing instruments. The company serves in the construction, the railroad, the highway, the water conservancy, the electric power, the university and the scienitic research institute.
To provide quality products, services and solutions for the industry,And establish a good long-term cooperative relationship with it. Our company always abides by the business philosophy of“customer first, quality firrst”.Do a good customer service,All products of the company implement the "three guarantees policy"
Q:What equipments do you supply?
A: We supply metal testing, pile testing, concrete testing, soil testing, cement testing, asphalt testing, rock testing and other building lab equipments.
Q: Are your company a trading one or a factory?
A: Factory+ trade (integration), More than 10 years focusing on test instruments field.
Q: After an order is placed, when to deliver?
A: Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days Please be aware that our production lead times depend on specific items and item quantities.
Q: What about the warranty with after-sales services?
A: The testing machine is guaranteed for 12 months by gaotiejian, we can help you to repair your problem con troller freely, even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handles guest problems and complaints in a professional and timely.
Q: What about the product' services and qualit?
A: Each instruments must be carried out 100% quality examination and test when shipping and delivery goods Product use training, each of our product provide video training to show you how to install operate We can arrange engineer to train the operation of equipment to customer s company when you need. products are widely recognized and trusted by users.
