Product Description
Asphalt compactor Automatic Marshall test
Automatic Marshall compactor use to produce Marshall Specimen from hot mix asphalt. Machine features a rotating mold mechanism and a hammer with a beveld foot, which together produce a kneading action when producing test pills. Test Machine’s automatic counter allows the operatör to preset the number of blows wanted and will turn off the machine when completed. The unit includes a compression pedestal,BS EN 598 safety standards for manufactured 12697 -30.This block contains a laminated wood 30 mm sq x 25 mm tick metal plate is protected. Mechanism of action in weight 4.53 kg,457 mm to the desired height to allow Access and free-fall. The unit is fully compliant to changes in standards.
| Power rating | 370W |
| Blows frequency | 55 blows in 55/60 s |
| Sliding mass weight | 4536 ± 9 g 10210±10g |
| Total hammer weight | 7850 ± 50 g |
| Free fall height | 457± 1.5 mm |
| Overall dimensions | 540*370*1750mm |
| Weight approx | 180kg |
| Power | 380V/220V |
| Compact preset range | 1-999 |
Exported in wooden boxes, with wooden pallets attached.
