New Model Soil Static Cone Penetrometers Cross Plate Shear Test Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Other
Year Established:
1994
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Manual Static Cone Penetrometer(CPT) Vane Shear Test ApparatusNegotiableMOQ: 1 -
Static Cone Penetration Test Apparatus With Vane ShearNegotiableMOQ: 1
-
30 kn Soil Cone Penetration Test / Static Cone PenetrometerNegotiableMOQ: 1
-
Procedure of Static Cone Penetration Test / Vane Shear Test MachineNegotiableMOQ: 1
-
Dual-Use Robust CPT Soil Standard Static Cone Penetration Test Apparatus ProcedureNegotiableMOQ: 1
Product Description
It is not only just the lightest CPT machine, but also vane shear test machine (i.e. VST). Its rated penetration force is 30KN
(3t) and the test depth is up to 30m (in soft soil area). While doing CPT test, it could work with 10cm2 probe, also 10cm2
pore-pressure probe while doing CPTu test. This machine is manual operation, suitable for clay, silt, sand, etc. After over 20
years application and development, now it is improved to put up a perfect performance. Vane shear test ranges 0 ~130KPa, Cross
Board To Board head configuration 50 × 100 (mm) (general) or 75 × 150 (mm) 75 × 100 (mm) (special)
(3t) and the test depth is up to 30m (in soft soil area). While doing CPT test, it could work with 10cm2 probe, also 10cm2
pore-pressure probe while doing CPTu test. This machine is manual operation, suitable for clay, silt, sand, etc. After over 20
years application and development, now it is improved to put up a perfect performance. Vane shear test ranges 0 ~130KPa, Cross
Board To Board head configuration 50 × 100 (mm) (general) or 75 × 150 (mm) 75 × 100 (mm) (special)
Specification
item | value |
Customized support | OEM, ODM |
Place of Origin | Hebei,China |
Brand Name | IWIN |
Model Number | IWIN-SCPT |
Power | Electronic |
force | 30KN |
Depth | 20-30m |
Test ranges | 0-130KPa |
Speed | 0.5-1m/min |
Probe diameter | 10CM 15CM |
Cross plate shear | <132Kpa |
Weight | 100 kg |
Software | APK |
Keyword | Static Cone Penetration Test |
Packing List: | ||||||
No. | Name | Amount | Unit | |||
1 | Main Frame | 1 | pcs | |||
2 | Probe | 20 | pcs | |||
3 | Ground anchor | 2 | pcs | |||
4 | Ground anchor iron | 2 | pcs | |||
5 | Ground anchor clamp | 2 | pcs | |||
6 | Anchor booster | 2 | pcs | |||
7 | Rocker | 2 | pcs | |||
8 | Mountain plate | 1 | pcs | |||
9 | Block | 1 | pcs | |||
10 | Guide sleeve | 2 | set | |||
11 | Probe Connector | 1 | pcs | |||
12 | Gauge | 1 | pcs | |||
13 | Single bridge probe | 1 | pcs | |||
14 | Adjustable joints | 20 | pcs | |||
15 | 4 core cable | 20 | m | |||
