Mechanical Property Testing Hydraulic Compression Testing Machine

Mechanical Property Testing Hydraulic Compression Testing Machine photo-1
Mechanical Property Testing Hydraulic Compression Testing Machine photo-2
Mechanical Property Testing Hydraulic Compression Testing Machine photo-3
Mechanical Property Testing Hydraulic Compression Testing Machine photo-4
Mechanical Property Testing Hydraulic Compression Testing Machine photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Other
Year Established:
1994
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Mechanical property testing hydraulic compression testing machine

Product Parameters

Mechanical property testing hydraulic compression testing machine

Mechanical property testing hydraulic compression testing machine

Mechanical property testing hydraulic compression testing machine

This series of testing machine takes hydraulic pressure as power, USES electro-hydraulic servo control technology to test the compressive mechanical properties of cement, mortar, brick, concrete and other building materials, and shows the loading force value, loading speed and loading curve. Test data is processed, stored and printed automatically.

Maximum test force(KN):

HYE- 2000

HYE-2000A

HYE-2000B

Test accuracy:

Level1

Level1

Level1

Space adjustment mode:

Block adjustment

Manual lead screw adjustment

Electric lead screw adjustment

travel of piston(mm):

80

80

80

Sensor type:

oil pressure

oil pressure

oil pressure

Maximum distance between two pressure plates(mm):

350

350

350

Size of upper platen(mm):

φ225

240×240

240×240

Lower platen size(mm):

φ295

350×260

350×260

motor power(KW):

0.75

0.75

0.75

Main engine dimensions(mm):

900×400×1250

985×600×800

985×600×800

total weight (kg):

920

900

910

Product advantages

 Mechanical property testing hydraulic compression testing machine

Product display

 Mechanical property testing hydraulic compression testing machine

Applications

 Mechanical property testing hydraulic compression testing machine



Related Products





About us

 Mechanical property testing hydraulic compression testing machine

FAQ



Q: Are your company a trading one or a factory?

A: Factory+ trade (integration), More than 10 years focusing on test instruments field.

Q: After an order is placed, How long it be delivered?

A: Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days Please be aware that our production lead times depend on specific items and item quantities.

Q: What about the warranty with after-sales services?

A: The testing machine is guaranteed for 12 months by gaotiejian, we can help you to repair your problem controller freely, even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handles guest problems and complaints in a professional and timely.

Q: What about the product' services and qualit

A: Each instruments must be carried out 100% quality examination and test when shipping and delivery goods Product use training, each of our product provide video training to show you how to install operate We can arrange engineer to train the operation of equipment to customers company when you need. Products are widely recognized and trusted by users.
