Allosun EM3642 Digital Cable Tester 2 in 1 Wire Tracker and Multi Meter Safety CATII 250V Electric Volt Amp Ohm Meter
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Allosun EM5510 Digital Multimeter 5 in 1 Sound Level Humidity Luminosity Autoranging Multimeter Temperature Tester
-
Allosun EM3212 Portable Digital Multimeter Pen Type Volt Ohm Ammeter Auto Range Multi-function Electric Test Meter
-
Allosun EM2283 Automotive Voltage Test Wire Break Point Detector Little Fuse Current Test
-
Allosun EM9807 GFCI Socket Tester Household Electrical Safety Kit GFCI TESTER Outlet Tester
-
All-sun GK4 Voltage Tester Pen Household Safety Kit
-
Allosun GK9A Automotive Voltage Meter Car Circuit Volt Tester
Product Description
Products Description
Digital Cable Tester 2 in 1 Wire Tracker and Multimeter
Safety CATII 250V Electric Volt Amp Ohm Meter
Features
1. Measures DC and AC voltage, DC and AC current, resistance, diode and continuity.
2. 3 1/2 digit LCD display for multimeter function.
3. Wire trace, continuity test, clear/busy.ringing line test, tip/ring identification, polarity indication.
4. Continuous or intermittent tone selection.
General Specification
Display: 3 1/2-digit LCD, with a max. reading of 1999, and with unit and symbol indication.
Multimeter Overrange Indication: "OL" shown on the display.
Multimeter Negative Polarity Indication: negative sign "-" shown on the display automatically.
Multimeter Sampling Rate: 2 to 3 times/sec
Operating Condition: 0°C to 40°C, <75%RH
Storage Condition: -10°C to 50°C, <85%RH
Power Supply: 1.5V AAA battery, 2 pieces (for multimeter)
9V 6F22 battery,1 piece (for cable tester)
9V 6F22 battery,1 piece (for receiver)
Multimeter Low Battery Indication: a battery icon shown on the display.
Size: (Master Unit) 190x85x55 mm (Receiver) 217x45x29 mm
Weight: about 360g (Master Unit) about 117g (Receiver)
Techinical Specification
DC Voltage: 200mV/2V/20V/200V/250V
AC Voltage: 2V/20V/200V/250V
DC Current: 200μA/2000μA/20mA/200mA
AC Current: 200μA/2000μA/20mA/200mA
Resistance: 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ
Diode Test: The display shows the approximate forward voltage drop of diode
Continuity Test: The built-in buzzer will sound if the resistance is less than about 30Ω.
The buzzer will not sound if the resistance is more than 100Ω
Safety CATII 250V Electric Volt Amp Ohm Meter
Features
1. Measures DC and AC voltage, DC and AC current, resistance, diode and continuity.
2. 3 1/2 digit LCD display for multimeter function.
3. Wire trace, continuity test, clear/busy.ringing line test, tip/ring identification, polarity indication.
4. Continuous or intermittent tone selection.
General Specification
Display: 3 1/2-digit LCD, with a max. reading of 1999, and with unit and symbol indication.
Multimeter Overrange Indication: "OL" shown on the display.
Multimeter Negative Polarity Indication: negative sign "-" shown on the display automatically.
Multimeter Sampling Rate: 2 to 3 times/sec
Operating Condition: 0°C to 40°C, <75%RH
Storage Condition: -10°C to 50°C, <85%RH
Power Supply: 1.5V AAA battery, 2 pieces (for multimeter)
9V 6F22 battery,1 piece (for cable tester)
9V 6F22 battery,1 piece (for receiver)
Multimeter Low Battery Indication: a battery icon shown on the display.
Size: (Master Unit) 190x85x55 mm (Receiver) 217x45x29 mm
Weight: about 360g (Master Unit) about 117g (Receiver)
Techinical Specification
DC Voltage: 200mV/2V/20V/200V/250V
AC Voltage: 2V/20V/200V/250V
DC Current: 200μA/2000μA/20mA/200mA
AC Current: 200μA/2000μA/20mA/200mA
Resistance: 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ
Diode Test: The display shows the approximate forward voltage drop of diode
Continuity Test: The built-in buzzer will sound if the resistance is less than about 30Ω.
The buzzer will not sound if the resistance is more than 100Ω
Product packaging
