Help CenterUrea Filling Machine
Related Products
Product introduction
This product is composed of filling nozzle, measuring platform, automatic filling control box, frame, roller conveyor, automatic capping machine, etc. It is suitable for the liquid that will not produce foam in the filling process, and has the function of automatic quantitative filling and automatic capping after filling. The high degree of automation will not lead to overflow in the operation of the filling liquid, clean and pollution-free. The material contact part (filling head embedded in the storage tank) is made of 316L stainless steel and Teflon sealing ring, suitable for strong acid, alkali and corrosive raw materials. Integral explosion-proof design, in strict accordance with GB3836 explosion-proof standard design, production, installation, inspection. It ensures the high reliability and precision of explosion-proof weighing instrument.
Scope of application
Filling scale storage tank type (10-60kg) is the weight of a large number of bulk liquid materials into a variety of containers, iron drums or plastic drums, for 1 ~ 5kg drums of automatic quantitative filling, widely used in chemical, food, pesticide and other liquid materials related to the industry, Suitable for coating, paint, ink, adhesive, curing agent, resin, dye, cleaning agent, oil, glycerin, lubricating oil, edible oil, essence, solvent, additives, food additives, pesticides and other dangerous chemical products and other products.
Functional features
˙ Product setting - store up to 10 different products weight set points and relevant filling parameters
˙ Man-machine interface - it can be easily calibrated on the weighing terminal; Fast setting of filling parameters on touch screen (optional)
˙ Difference correction - Automatically correct the advance amount after filling each barrel, so that the next bucket of filling is closer to the target value
˙ Tolerance check - Check the tolerance of the full bucket, can effectively prevent the overflow of materials
˙ Data statistics - including weight accumulation, the number of cumulative, can be connected with the computer, data management (optional)
˙ Multi-stage filling
