15kg 30kg Vacuum Silver Bar Making Machine for High Quality Silver Bar Casting
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2008
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Buy the Most Suitable Xrf Gold Testing Machine for JewelersNegotiableMOQ: 1 -
CDOCAST SAP9000 Nondestructive Analysis Metals Gold Analyzer MachineNegotiableMOQ: 1
-
High Quality Long Service Life Xrf Gold Analyzer Price for Testing Gold Silver Platinum and PalladiumNegotiableMOQ: 1
-
XRF 2021 New Hot Sale Cheap Metals Testing Machine for Gold, Silver, Platinum, PalladiumNegotiableMOQ: 1
-
Buy the Best XRF Gold Purity Tester of Precious Metals JewelryNegotiableMOQ: 1
Products Description
15kg 30kg vacuum silver bar making machine for high quality silver bar casting
The CDOCAST vacuum gold silver bar making machine can cast up to 15Kg-30kg of gold bars .We can also customize the machine to make gold ingots of different size according to customer needs. 15kg-30kg gold bars casting need the power supply of 80kw, the bigger bar cast, the more power required.
Due to the enclosed vacuum melting condition, our vacuum gold bar casting machine has almost no precious metal loss which Greatly reduce the loss of customers.
Due to the enclosed vacuum melting condition, our vacuum gold bar casting machine has almost no precious metal loss which Greatly reduce the loss of customers.
Details Images
Product Paramenters
Model number |
CDO-F plus |
Power source |
Three phase 380V±10%, 50/60Hz |
Power |
80 kw |
Applicable metal |
Gold,silver and copper |
Casting time |
15-25 min |
Cooling time |
15-20 min |
Cooling mode |
Water cooling |
The Max capacity |
1 pcs of 30kg bar or customized |
Max temperature |
1800℃ |
Dimension |
1640*980*1640 mm |
Weight |
About 600 kg |
Protective gas |
Nitrogen or argon |
Vacuum pump |
63 m³/hour |
Application
Feature
1: Our Vacuum gold bar casting machine comes with the plc touch screen system control, the operator only has to filled in the graphite mould with the pre-weighted raw material, like gold powder, gold grain, close the door of the melting chamber as well as press the START switch to release the automatic cycle, the casting will started automaticly, after finished the casting cycle, you can abtain the gold or silver bar which is ready for the market.
2:The induction coil of the vacuum gold bar making machine is custom designed to be either square or rectangular in shape, with a water cooling plate in the middle of the coil. After melting, the cooling plate will be jacked up by a cylinder to rapidly cool the graphite mould, allowing the graphite cover and graphite mould to reach the same temperature, resulting in a bright and flat surface.
3:The entire casting process consists of melting and cooling process, with melting times ranging from 6 to 12 minutes, depending on the size of the bars The cooling time is usually recommended to be 8 minutes or more, as this will maximise the lifetime of the graphite mould.
4:24-hour continuous operation, thus satisfying customers with high production output requirements.
5:There is no need for engineers to install and debug onsite. Each gold bar casting machine comes with installation and debugging video. Under the video guidance, you can simply complete the installation and start to run our furnace,what is more,each vacuum gold bar making machine produced by CDOCAST will be strictly tested before leaving the factory to ensure stable quality Catalog
2:The induction coil of the vacuum gold bar making machine is custom designed to be either square or rectangular in shape, with a water cooling plate in the middle of the coil. After melting, the cooling plate will be jacked up by a cylinder to rapidly cool the graphite mould, allowing the graphite cover and graphite mould to reach the same temperature, resulting in a bright and flat surface.
3:The entire casting process consists of melting and cooling process, with melting times ranging from 6 to 12 minutes, depending on the size of the bars The cooling time is usually recommended to be 8 minutes or more, as this will maximise the lifetime of the graphite mould.
4:24-hour continuous operation, thus satisfying customers with high production output requirements.
5:There is no need for engineers to install and debug onsite. Each gold bar casting machine comes with installation and debugging video. Under the video guidance, you can simply complete the installation and start to run our furnace,what is more,each vacuum gold bar making machine produced by CDOCAST will be strictly tested before leaving the factory to ensure stable quality Catalog
Packaging & Shipping
Our services
I.Commissioned from the furnace after delivery, into the warranty period, the warranty period of 12 months.Regardless of the warranty period or warranty period, the furnace, such as failure, received a notice, we are committed to 36 hours to send to the scene to deal with.
II.In the warranty period by our cause failure, we carried out unconditional maintenance and replacement.Due to other causes ofthe failure, we only charge the cost of paid maintenance
III.After the warranty period, we will, as always, do a good job after-sales service, so that users no worries.
I.Commissioned from the furnace after delivery, into the warranty period, the warranty period of 12 months.Regardless of the warranty period or warranty period, the furnace, such as failure, received a notice, we are committed to 36 hours to send to the scene to deal with.
II.In the warranty period by our cause failure, we carried out unconditional maintenance and replacement.Due to other causes ofthe failure, we only charge the cost of paid maintenance
III.After the warranty period, we will, as always, do a good job after-sales service, so that users no worries.
Customer Photos
FAQ
1. What is your advantage compared to others?
First, we provided turnkey solution, Cost-effective, highly efficient, durable, and easy-to-operate machine is what we deliver.Second, we have a Strict Quality Control System, Before Being dispatched from our factory all of our equipment will undergo a series of strict test, including the appearance quality test, voltage electrical test, aging test also the package strength checking.
2. If our machine meets fault, how could you help us to solve it?
For failures caused by using process, we will send our aftersales engineer to discuss with you, and you should provide the video of how the machine is broken, we will find out which part of the machine is broken, and then we will send you the broken part By DHL.
3. what is your warranty?
Our warranty period comes from the machine begin to run normally and we will provide the whole life technology support to you for free.
All products sold by COOLDO In the warranty period, we will provide you the spare parts for free. Our engineer will help you do the aftersales through our remote control system. When out of one year warranty time, we will provide the spare parts with the cost price for the whole machine lifetime.
First, we provided turnkey solution, Cost-effective, highly efficient, durable, and easy-to-operate machine is what we deliver.Second, we have a Strict Quality Control System, Before Being dispatched from our factory all of our equipment will undergo a series of strict test, including the appearance quality test, voltage electrical test, aging test also the package strength checking.
2. If our machine meets fault, how could you help us to solve it?
For failures caused by using process, we will send our aftersales engineer to discuss with you, and you should provide the video of how the machine is broken, we will find out which part of the machine is broken, and then we will send you the broken part By DHL.
3. what is your warranty?
Our warranty period comes from the machine begin to run normally and we will provide the whole life technology support to you for free.
All products sold by COOLDO In the warranty period, we will provide you the spare parts for free. Our engineer will help you do the aftersales through our remote control system. When out of one year warranty time, we will provide the spare parts with the cost price for the whole machine lifetime.
