 1.25g 1310/1550nm LC SC 40km bidi sfp

Description



1).The bidi sfp 40km are high performance, cost effective modules supporting data-rate of 155Mbps and up to 120km transmission distance with SMF



2).The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.



3).The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.





Main Features

1.bidi sfp

2. Dual data-rate of 1.25Gbps/1.063Gbps operation Tx1550nm-Rx1310nm

 3.Compliant with SFP MSA and SFF-8472 with simplex LC receptacle

 4.Digital Diagnostic Monitoring:

 5.Internal Calibrationor External Calibration

 6.Compatible with SONET OC-24-LR-1

7. Compatible with RoHS

 8.+3.3V single power supply

 9.Operating case temperature: Standard : 0 to +70°C



 Applications

 Gigabit Ethernet

 Fiber Channel

 Switch to Switch interface

 Switched backplane applications

 Router/Server interface

 Other optical transmission systems



 Products List of bidi sfp

Part Number Data Rate Wavelenth Distance Package Temp. Source
BIDI SFP (155M/1.25G LC Interface) without DDMI
RBSFP-0335L-L2 155M 1310/1550 0-20km SFP 0~70 FP+PIN
RBSFP-0353L-L2 155M 1550/1310 0-20km SFP 0~70 FP+PIN
RBSFP-0334L-L2 155M 1310/1490 0-20km SFP 0~70 FP+PIN
RBSFP-0343L-L2 155M 1490/1310 0-20km SFP 0~70 DFB+PIN
RBSFP-0335L-L4 155M 1310/1550 40KM SFP 0~70 FP+PIN
RBSFP-0353L-L4 155M 1550/1310 40KM SFP 0~70 DFB+PIN
RBSFP-0334L-L4 155M 1310/1490 40KM SFP 0~70 FP+PIN
RBSFP-0343L-L4 155M 1490/1310 40KM SFP 0~70 DFB+PIN
RBSFP-0335L-L6 155M 1310/1550 60KM SFP 0~70 DFB+PIN
RBSFP-0353L-L6 155M 1550/1310 60KM SFP 0~70 DFB+PIN
RBSFP-0334L-L6 155M 1310/1490 60KM SFP 0~70 DFB+PIN
RBSFP-0343L-L6 155M 1490/1310 60KM SFP 0~70 DFB+PIN
RBSFP-0335L-L8 155M 1310/1550 80KM SFP 0~70 DFB+PIN
RBSFP-0353L-L8 155M 1550/1310 80KM SFP 0~70 DFB+PIN
RBSFP-2435L-02 1.25G 1310/1550 2KM SFP 0~70 FP+PIN
RBSFP-2453L-02 1.25G 1550/1310 2KM SFP 0~70 FP+PIN
RBSFP-2435L-L2 1.25G 1310/1550 0-20KM SFP 0~70 FP+PIN
RBSFP-2453L-L2 1.25G 1550/1310 0-20KM SFP 0~70 DFB+PIN
RBSFP-2434L-L2 1.25G 1310/1490 0-20KM SFP 0~70 FP+PIN
RBSFP-2443L-L2 1.25G 1490/1310 0-20KM SFP 0~70 DFB+PIN
RBSFP-2435L-L4 1.25G 1310/1550 40KM SFP 0~70 DFB+PIN
RBSFP-2453L-L4 1.25G 1550/1310 40KM SFP 0~70 DFB+PIN
RBSFP-2434L-L4 1.25G 1310/1490 40KM SFP 0~70 DFB+PIN
RBSFP-2443L-L4 1.25G 1490/1310 40KM SFP 0~70 DFB+PIN
RBSFP-2435-L6 1.25G 1310/1550 60KM SFP 0~70 DFB+PIN
RBSFP-2453-L6 1.25G 1550/1310 60KM SFP 0~70 DFB+APD
RBSFP-2445L-L6 1.25G 1490/1550 60KM SFP 0~70 DFB+PIN
RBSFP-2454L-L6 1.25G 1550/1490 60KM SFP 0~70 DFB+PIN
RBSFP-2445L-L8 1.25G 1490/1550 80KM SFP 0~70 DFB+PIN
RBSFP-2454L-L8 1.25G 1550/1490 80KM SFP 0~70 DFB+PIN
RBSFP-4835L-L2 2.5G 1310/1550 20KM SFP 0~70 DFB+PIN
RBSFP-4853L-L2 2.5G 1310/1550 20KM SFP 0~70 DFB+PIN
BIDI SFP (155M/1.25G LC Interface) with DDMI
RBSFP-0335L-L2D 155M 1310/1550 0-20km SFP 0~70 FP+PIN
RBSFP-0353L-L2D 155M 1550/1310 0-20km SFP 0~70 FP+PIN
RBSFP-0334L-L2D 155M 1310/1490 0-20km SFP 0~70 FP+PIN
RBSFP-0343L-L2D 155M 1490/1310 0-20km SFP 0~70 DFB+PIN
RBSFP-0335L-L4D 155M 1310/1550 40KM SFP 0~70 FP+PIN
RBSFP-0353L-L4D 155M 1550/1310 40KM SFP 0~70 DFB+PIN
RBSFP-0334L-L4D 155M 1310/1490 40KM SFP 0~70 FP+PIN
RBSFP-0343L-L4D 155M 1490/1310 40KM SFP 0~70 DFB+PIN
RBSFP-0335L-L6D 155M 1310/1550 60KM SFP 0~70 DFB+PIN
RBSFP-0353L-L6D 155M 1550/1310 60KM SFP 0~70 DFB+PIN
RBSFP-0334L-L6D 155M 1310/1490 60KM SFP 0~70 DFB+PIN
RBSFP-0343L-L6D 155M 1490/1310 60KM SFP 0~70 DFB+PIN
RBSFP-0335L-L8D 155M 1310/1550 80KM SFP 0~70 DFB+PIN
RBSFP-0353L-L8D 155M 1550/1310 80KM SFP 0~70 DFB+PIN
RBSFP-2435L-02D 1.25G 1310/1550 2KM SFP 0~70 FP+PIN
RBSFP-2453L-02D 1.25G 1550/1310 2KM SFP 0~70 FP+PIN
RBSFP-2435L-L2D 1.25G 1310/1550 20KM SFP 0~70 FP+PIN
RBSFP-2453L-L2D 1.25G 1550/1310 20KM SFP 0~70 DFB+PIN
RBSFP-2434L-L2D 1.25G 1310/1490 20KM SFP 0~70 FP+PIN
RBSFP-2443L-L2D 1.25G 1490/1310 20KM SFP 0~70 DFB+PIN
RBSFP-2435L-L4D 1.25G 1310/1550 40KM SFP 0~70 DFB+PIN
RBSFP-2453L-L4D 1.25G 1550/1310 40KM SFP 0~70 DFB+PIN
RBSFP-2434L-L4D 1.25G 1310/1490 40KM SFP 0~70 DFB+PIN
RBSFP-2443L-L4D 1.25G 1490/1310 40KM SFP 0~70 DFB+PIN
RBSFP-2435L-L6D 1.25G 1310/1550 60KM SFP 0~70 DFB+PIN
RBSFP-2453L-L6D 1.25G 1550/1310 60KM SFP 0~70 DFB+APD
RBSFP-2445L-L6D 1.25G 1490/1550 60KM SFP 0~70 DFB+PIN
RBSFP-2454L-L6D 1.25G 1550/1490 60KM SFP 0~70 DFB+PIN
RBSFP-2445L-L8D 1.25G 1490/1550 80KM SFP 0~70 DFB+PIN
RBSFP-2454L-L8D 1.25G 1550/1490 80KM SFP 0~70 DFB+PIN

BIDI SFP (155M/1.25G SC Interface) without DDMI
RBSFP-0335S-L2 155M 1310/1550 0-20km SFP 0~70 FP+PIN
RBSFP-0353S-L2 155M 1550/1310 0-20km SFP 0~70 FP+PIN
RBSFP-0334S-L2 155M 1310/1490 0-20km SFP 0~70 FP+PIN
RBSFP-0343S-L2 155M 1490/1310 0-20km SFP 0~70 DFB+PIN
RBSFP-0335S-L4 155M 1310/1550 40KM SFP 0~70 FP+PIN
RBSFP-0353S-L4 155M 1550/1310 40KM SFP 0~70 DFB+PIN
RBSFP-0334S-L4 155M 1310/1490 40KM SFP 0~70 FP+PIN
RBSFP-0343S-L4 155M 1490/1310 40KM SFP 0~70 DFB+PIN
RBSFP-0335S-L6 155M 1310/1550 60KM SFP 0~70 DFB+PIN
RBSFP-0353S-L6 155M 1550/1310 60KM SFP 0~70 DFB+PIN
RBSFP-0334S-L6 155M 1310/1490 60KM SFP 0~70 DFB+PIN
RBSFP-0343S-L6 155M 1490/1310 60KM SFP 0~70 DFB+PIN
RBSFP-2435S-02 1.25G 1310/1550 2KM SFP 0~70 FP+PIN
RBSFP-2453S-02 1.25G 1550/1310 2KM SFP 0~70 FP+PIN
RBSFP-2435S-L2 1.25G 1310/1550 20KM SFP 0~70 FP+PIN
RBSFP-2453S-L2 1.25G 1550/1310 20KM SFP 0~70 DFB+PIN
RBSFP-2434S-L2 1.25G 1310/1490 20KM SFP 0~70 FP+PIN
RBSFP-2443S-L2 1.25G 1490/1310 20KM SFP 0~70 DFB+PIN
RBSFP-2435S-L4 1.25G 1310/1550 40KM SFP 0~70 DFB+PIN
RBSFP-2453S-L4 1.25G 1550/1310 40KM SFP 0~70 DFB+PIN
RBSFP-2434S-L4 1.25G 1310/1490 40KM SFP 0~70 DFB+PIN
RBSFP-2443S-L4 1.25G 1490/1310 40KM SFP 0~70 DFB+PIN





1.25g 1310/1550nm LC SC 40km bidi sfp





 1.25g 1310/1550nm LC SC 40km bidi sfp1.25g 1310/1550nm LC SC 40km bidi sfp1.25g 1310/1550nm LC SC 40km bidi sfp
