High Quality Green Optical FTTH ESC250D SC APC Fiber Optic Fast Connector

FOB Price

Negotiable

1 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Fast Connector Features

Fast Connector Applications

Patch panels
Distribution frames
Maintenance or emergency restoration of fiber networks
FTTH Outlets
Connection at the desk for LAN environments
Suitable for FTTx butterfly type cable(both square and circle shape are available)

Fast Connector Parameters

Fast Connector Specification
Mode	SM		MM
Polish	UPC	APC	PC
Insertion Loss	Typical ≤0.2dB Maximum ≤0.3dB		≤0.25dB

Return Loss	≥50dB	≥65dB	≥35dB
Interchangeability	≤0.2dB
Repeatability	≤0.1dB
Durability	≤0.2dB (1000 times mating)
Tensile Strengh	> 10kg
Temperature	≤0.2dB (-40+85 sustain 100 hours)
Humidity	≤0.2dB (+25+65 93 R.H.100 hours)
