1x8 plc splitter SC/UPC splitter rmini fiber optic plc splitter
- 1000 per Month
- T/T Credit Card
- 1 x 16 sc/upc steel mini plc splitter 1 x 2/4/8/16 SC/UPC fiber optic plc splitter
- plc splitter plc 1 x4 SC/APC splitter rmini fiber optic plc splitter
- 1x8 plc splitter plc 1x2/4/8/16 SC/APC SC/UPC splitter rmini fiber optic plc splitter
- 1x16 plc splitter fibra caja de distribucion ftth rmini fiber optic plc splitter
- plc splitter plc 1 x 2 SC/UPC splitter rmini fiber optic plc splitter
- Fiber optic equipment 1260 to 1650nm ftth optic fiber plc splitter 1x2/1x4/1x8
Product Description
*Excellent Mechanical,Small Size
*High Reliability
*Low insertion Loss and low Polarization Dependent loss
*High channel counts
*Excellent Environmental Stability and Widely Used
Operating Wavelength (nm) |
1260 ~ 1650 |
||||||||
Type |
1x4 |
1x8 |
1x16 |
2x4 |
2x8 |
2x16 |
1x32 |
2x32 |
1x64 |
Insertion Loss (dB) Max. * |
<7.3 |
<10.5 |
<13.5 |
<7.6 |
<11.2 |
<14.5 |
<16.2 |
<18.2 |
<20.5 |
Uniformity (dB) Max.* |
<0.8 |
<1.0 |
<1.5 |
<1.0 |
<1.5 |
<2.0 |
<2.0 |
<2.5 |
<2.5 |
PDL(dB)Max.* |
<0.2 |
<0.2 |
<0.3 |
<0.3 |
<0.3 |
<0.4 |
<0.3 |
<0.4 |
<0.3 |
Directivity (dB) Min * |
55 |
||||||||
Return Loss (dB) Min * |
55(50) |
||||||||
Operating Temperature (°C) |
-5~ +75 |
||||||||
Storage Temperature (°C) |
-40 ~ +85 |
||||||||
Fiber length |
1m or custom length |
||||||||
Fiber Type |
Corning SMF-28e fiber |
||||||||
Connector Type |
Custom specified |
||||||||
Power Handling (mW) |
300 |
