Home > Products > Pillow Block Bearing > 3/4" Pillow Block Bearing UCP204-12 Stainless Steel
3/4" Pillow Block Bearing UCP204-12 Stainless Steel
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
5/8\" Pillow Block Bearing UCP202-10
-
Low Friction Pillow Block Bearing UKP209+H2309
-
Original Bearing Price UCP 205 Bearing Pillow Block Bearing
-
Pillow Block Bearing P207 P205 P206 Pillow Block Sizes
-
KFL08 Pillow Block Bearing 8mm Flange Bearing For CNC
-
Pillow Bearings Pillow Block Bearing Bearings Bracket FY 25 TF
Product Description
Product Description
Product Name | 3/4" Pillow Block Bearing UCP204-12 |
Bearing Type | Pillow Block Bearing |
Shaft Size | 3/4" |
Stock | Rich Stocks |
Warranty | 18 month |
Sample | Available |
Description.
The UCP204-12 3/4" pillow block bearing unit is equipped with two specially designed setscrews positioned in the inner ring of the ball bearing to lock onto the shaft. The pillow block set screws are placed at a 90-degree angle to optimize balance between holding power and inner ring distortion. The UCP204-12 3/4" pillow block bearings are relubricatable and offer a full-width inner ring for added stability.
The UCP204-12 pillow block bearing also features a positive-contact, three-piece, fiber-imbedded R-seal to protect against harmful contaminants and retain lubricant. The setscrew locking mechanism on the pillow block bearing is easy to install and well suited for reversing applications and normal loads.
Applications for the UCP204-12 3/4" pillow block bearing include: Construction, Conveyors, Food and Beverage, Packaging and General Industrial Equipment.
d | 19.05 mm |
d1 | ≈ 28.7 mm |
A | 34 mm |
A1 | 23 mm |
B | 31 mm |
B4 | 5 mm |
H | 33.3 mm |
J | 95 mm |
Bearing Numbers
BEARING | ID | OD | WD |
CODE | (mm) | (mm) | (mm) |
UCP203 | 17 | 27.4 | 129 |
UCP204 | 20 | 30 | 134 |
UCP205 | 25 | 34.1 | 142 |
UCP206 | 30 | 38.1 | 167 |
UCP207 | 35 | 42.9 | 172 |
UCP208 | 40 | 49.2 | 186 |
UCP209 | 45 | 49.2 | 192 |
UCP210 | 50 | 51.6 | 208 |
UCP211 | 55 | 55.6 | 233 |
UCP212 | 60 | 65.1 | 243 |
UCP213 | 65 | 65.1 | 268 |
UCP214 | 70 | 74.6 | 274 |
UCP215 | 75 | 77.8 | 300 |
UCP216 | 80 | 82.6 | 305 |
UCP217 | 85 | 85.7 | 330 |
UCP218 | 90 | 96 | 356 |
UCP220 | 100 | 108 | 390 |
UCP305 | 25 | 38 | 175 |
UCP306 | 30 | 43 | 180 |
UCP307 | 35 | 48 | 210 |
UCP308 | 40 | 52 | 220 |
UCP309 | 45 | 57 | 245 |
UCP310 | 50 | 61 | 275 |
UCP311 | 55 | 66 | 310 |
UCP312 | 60 | 71 | 330 |
UCP313 | 65 | 75 | 340 |
UCP314 | 70 | 78 | 360 |
UCP315 | 75 | 82 | 380 |
UCP316 | 80 | 86 | 400 |
UCP317 | 85 | 96 | 420 |
UCP318 | 90 | 96 | 430 |
UCP319 | 95 | 103 | 470 |
UCP320 | 100 | 108 | 490 |
UCP321 | 105 | 112 | 490 |
UCP322 | 110 | 117 | 520 |
UCP324 | 120 | 126 | 570 |
UCP326 | 130 | 135 | 600 |
UCP328 | 140 | 145 | 620 |
