HK0808 Roller Bearing Needle Roller Bearing Famous Brands

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Features and benefits

Description..

Drawn cup needle roller bearings have a deep drawn, thin-walled outer ring. Drawn cup needle roller bearings are typically used in applications where the housing bore cannot be used as a raceway for a needle roller and cage assembly, but where a very compact and economical bearing arrangement is required. These bearings are mounted with a tight interference fit in the housing. That enables a simple and economic design of the housing bore, as shoulders or snap rings are not required to locate the bearing
axially.

* Low cross section
In applications where less space is available, needle roller bearings offer a very compact solution .
* High load carrying capacity
Despite their low cross sectional height, they have a high load carrying capacity.
* Separable design
The possibility of assembling inner and outer rings separately permits interference fits for shaft and housing and also enables easy maintenance inspections .
* High stiffness
Owing to their large number of small-diameter rollers, needle roller bearings with machined rings have high stiffness .
* Accommodate axial displacement
Needle roller bearings with machined rings can accommodate axial displacement . When using raceways on the shaft, the displacement distance is not limited by the bearing.

Bearing Number

Model No.	Inner Diameter	Outer Diameter	Width
NK 18/16	18	26	16
NK 18/20	18	26	20
NK 19/16	19	27	16
NK 19/20	19	27	20
NK 20/16	20	28	16
NAO 25x42x16	25	42	16
NAO 25x42x32	25	42	32
NAO 30x45x17	30	45	17
NAO 30x45x26	30	45	26
NAO 30x47x16	30	47	16
NAO 30x47x18	30	47	18
NAO 35x50x17	35	50	17
NAO 35x55x20	35	55	20
NA 4822	110	140	30
NA 4824	120	150	30
NKI 70/25	70	95	25
NKI 70/35	70	95	35
NKI 75/25	75	105	25
NAO 40x55x17	40	55	17
NAO 50x68x20	50	68	20
NKI 7/12 TN	7	17	12
NKI 7/16 TN	7	17	16
NKI 80/25	80	110	25
NKS 65	65	85	28
NKS 70	70	90	28
NKS 75	75	95	28
NKIS 15	15	35	20
NKIS 17	17	37	20
NKIS 20	20	42	20
NKI 45/25 TN	45	62	25
NKI 45/35 TN	45	62	35
NKI 5/12 TN	5	15	12
NA 4910 RS	50	72	23
NA 4910.2RS	50	72	23
NA 4911	55	80	25
NA 4912	60	85	25
NA 4913	65	90	25
NA 4914	70	100	30
NA 4915	75	105	30
NA 4916	80	110	30
NA 4917	85	120	35
NA 4918	90	125	35
NKI 50/35	50	68	35
NKI 55/25 TN	55	72	25
NKI 55/35	55	72	35
NK 16/16	16	24	16
NA 4826	130	165	35
NA 4828	140	175	35
NA 4830	150	190	40
NA 4832	160	200	40
NA 4834	170	215	45
NA 4836	180	225	45
NA 4838	190	240	50
NA 4840	200	250	50
NA 4848	240	300	60
NA 4852	260	320	60
NKIS 25	25	47	22
NKIS 30	30	52	22
NKIS 35	35	58	22

Company Profile

——————ABOUT US——————

Kenworth Machinery Equipment International Co.,Ltd.

With partnerships with the leading bearing manufacturers .We pride ourselves on only providing our clients with bearing that are manufactured to the highest standard using only the best quality materials.

Packing & Delivery

1. Industrial packaging: plastic bag + carton paper + carton or wooden ; plastic tube + carton 2. Commercial packing: 1pic/plastic bag + color box + carton 3. According to customs' requirements
