5205 Angular Contact Ball Bearing 5205-2RS 5205-ZZ
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
- BDZ38-1J Wheel Hub Bearing BDZ38-1 Double Row Ball Bearing 38x68x26mm
- VEB40 /NS 7CE Spindle Precision Machine Tool bearing 71908CE/HP4 71908
- VEX45 7CE1 Angular Contact Ball Bearings HS7009C.T.P4S. spindle bearing 7009 P4
- 71905 7905 NSK spindle bearing 7905CTYNDULP4
- 760206TN1/P4 High precision ball screw support bearing FL760206 Angular contact ball bearing FL 760206 P4DBB
- h7009c2rs p4dt Spindle bearing 7009C P4 Hybrid Angular Contact Ball Bearings H7009C 2RZ/P4 DB DT DF
Product Description
Product Description
double row Angular Contact Ball Bearing 5205 5205zz 5205 2rs bearings
Angular contact ball bearings have inner and outer ring raceways that are displaced relative to each other in the direction of the bearing axis. This means that these bearings are designed to accommodate combined loads, i.e. simultaneously acting radial and axial loads.
The axial load carrying capacity of angular contact ball bearings increases as the contact angle increases. The contact angle is defined as the angle between the line joining the points of contact of the ball and the raceways in the radial plane, along which the combined load is transmitted from one raceway to another, and a line perpendicular to the bearing axis.
double row angular contact ball bearings corresponds to two single row angular contact ball bearings arranged back-to-back.
Bearing name: | 5205Angular Contact Ball Bearing 5205-2RS |
d | 25 mm |
D | 52 mm |
B | 20.6 mm |
Reference | 5205Angular Contact Ball Bearing 5205-2RS |
Weight | 0.19 kg |
skype | have stock |
whatsapp | +8618710180456 |
email | sales1@landlionbearing.com |
Detailed Images
Bearing | Dimensions(mm) | Weight(kg) | ||||||||||
The base type | Variant | d | D | B | ||||||||
Now | old | cover | Ring | |||||||||
3203A | 5203 | ZZ | 2RS | 17 | 40 | 17.5 | 0.085 | |||||
3204A | 5204 | ZZ | 2RS | 20 | 47 | 20.6 | 0.12 | |||||
3205A | 5205 | ZZ | 2RS | 25 | 52 | 20.6 | 0.19 | |||||
3206A | 5206 | ZZ | 2RS | 30 | 62 | 23.8 | 0.3 | |||||
3207A | 5207 | ZZ | 2RS | 35 | 72 | 27 | 0.47 | |||||
3208A | 5208 | ZZ | 2RS | 40 | 80 | 30.2 | 0.58 | |||||
3209A | 5209 | ZZ | 2RS | 45 | 85 | 30.2 | 0.62 | |||||
3210A | 5210 | ZZ | 2RS | 50 | 90 | 30.2 | 0.67 | |||||
3211A | 5211 | ZZ | 2RS | 55 | 100 | 33.3 | 0.96 | |||||
3212A | 5212 | ZZ | 2RS | 60 | 110 | 36.5 | 1.37 | |||||
3213A | 5213 | ZZ | 2RS | 65 | 120 | 38.1 | 1.68 | |||||
3214A | 5214 | ZZ | 2RS | 70 | 125 | 39.7 | 1.82 | |||||
3215A | 5215 | ZZ | 2RS | 75 | 130 | 41.3 | 1.95 | |||||
3216A | 5216 | ZZ | 2RS | 80 | 140 | 44.4 | 2.55 | |||||
3303A | 5303 | ZZ | 2RS | 17 | 47 | 22.2 | 0.13 | |||||
3304A | 5304 | ZZ | 2RS | 20 | 52 | 22.2 | 0.22 | |||||
3305A | 5305 | ZZ | 2RS | 25 | 62 | 25.4 | 0.33 | |||||
3306A | 5306 | ZZ | 2RS | 30 | 72 | 30.2 | 0.51 | |||||
3307A | 5307 | ZZ | 2RS | 35 | 80 | 34.9 | 0.8 | |||||
3308A | 5308 | ZZ | 2RS | 40 | 90 | 36.5 | 1.08 | |||||
3309A | 5309 | ZZ | 2RS | 45 | 100 | 39.7 | 1.45 | |||||
3310A | 5310 | ZZ | 2RS | 50 | 110 | 44.4 | 1.98 | |||||
3311A | 5311 | ZZ | 2RS | 55 | 120 | 49.2 | 2.35 | |||||
3312A | 5312 | ZZ | 2RS | 60 | 130 | 54 | 3.2 | |||||
3313A | 5313 | ZZ | 2RS | 65 | 140 | 58.7 | 3.9 | |||||
3314A | 5314 | ZZ | 2RS | 70 | 150 | 63.5 | 4.95 | |||||
3315A | 5315 | ZZ | 2RS | 75 | 160 | 68.3 | 5.7 | |||||
3316A | 5316 | ZZ | 2RS | 80 | 170 | 68.3 | 7 |
Recommend Products
Product packaging
Packing :
1. Industrial packing
2. Single box +carton +pallets
3. According to customers demand
Delivery time :
1. Generally after payment: within 3 days .
2. If need produce , about 30 days
Payment
A less USD1000 , 100% T/T in advance .
1. More USD1000 , 30% T/T in advance , 70%T/T before shipment
Shipping
PACKING:bag+box+carton+pallet/wooden case.
Shipping : by sea/by air/by express like EMS FEDEX TNT DHL...
Factory
Warehouse
workshop
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory and trader .
Q: How long is your delivery time?
A: Generally it is 1-3 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
A: We are factory and trader .
Q: How long is your delivery time?
A: Generally it is 1-3 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
