Products Description
High quality glass processing machinery for 10mm thickness bathroom glass mirror cutter multi heads cnc glass cutting machine
Technical Paremeters
Model
SKQ-1313/1325
Working area
1300*1300mm/1300*2500mm
Body Structure
Thicken Steel Made Lathe
Rails
Taiwan HIWIN Square Rails
Transmission Type
Taiwan TBI Ball Screw
Max Moving Speed
40000mm/min
Max Cutting Speed
20000mm/min
Interface
USB
Voltage
220V/single phase or other can be customized
Drive Type
Stepper Motor& Leadshine Drivers
Working Dictate
G Code
Operating System
NC-studio Control System
Software
Artcam 8.1 (free supply)
Oil Lubricator
YES, Include
Wire Protect
YES, Include
Running Environment
Temperature:-10℃~45℃
After Packed Size
3.5*2.2*1.80M

Main Features

1. Our cnc glass cutting machine is welded with seamless steel structure,which is high temperatureannealing and vibrating stress relief,so the lathe body is stable and will not deform forvever.
2.Three axises adopt taiwan brand linear guide rails with high precision.
3. Z axis adopts imported Germany or Taiwan made ball screw, so high precision and long life time using are assured.
4. X and Y axis is transmitted by helical rack and pinion. This makes the machine work faster and has larger cutting force compared with ball screw transmission.
5. Well compatibility: CAD/CAM designing software, such as type3/castmate/wentai/artcam, etc.
6. Our cnc glass cutting machine has the function of re-carving after break point or power failure and it can estimate the processing time.
7 Manual/automatic oil-injection system allows the machine maintenance mush easier.
