Household Eco-Friendly Water Heater Roof Top Energy Solar Water Heater Collector Solar Hot Water Heater
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
2013
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Easy Installation And Convenient Pressurized Solar Energy System Split Solar Water HeaterNegotiableMOQ: 1 -
Super Metal Heat Pipe Solar Water Heater Separated With Pressurized TankNegotiableMOQ: 1
-
Energy-effect Split High Pressurized Solar Water HeaterNegotiableMOQ: 1
-
Best Selling Split Solar Water Heater Pressurized Rooftop Solar Thermal Systems Water HeatersNegotiableMOQ: 1
-
Hot Selling Low Price High Quality CE/ISO9001/CCC Compact Pressured 200L Color Steel Solar Water HeaterNegotiableMOQ: 1
Product Description
Specification: |
||||||
Item |
Tube Specification(mm) |
Absorb Area(m2) |
Person |
|||
SR-SP-5818-10-100 |
Φ58×1800×10 |
0.82 |
1-2 |
|||
SR-SP-5818-12-120 |
Φ58×1800×12 |
0.98 |
||||
SR-SP-5818-15-150 |
Φ58×1800×15 |
1.22 |
2-3 |
|||
SR-SP-5818-18-180 |
Φ58×1800×18 |
1.46 |
||||
SR-SP-5818-20-200 |
Φ58×1800×20 |
1.62 |
3-4 |
|||
SR-SP-5818-24-240 |
Φ58×1800×24 |
1.95 |
||||
SR-SP-5818-30-300 |
Φ58×1800×30 |
2.45 |
4-5 |
|||
SR-SP-5818-36-300 |
Φ58×1800×36 |
2.92 |
||||
SR-SP-5818-40-400 |
Φ58×1800×40 |
3.24 |
5-6 |
|||
SR-SP-5818-50-500 |
Φ58×1800×50 |
4.06 |
6-9 |
|||
Specifications:
1.vacuum tube:Vacuum Tube With Copper Heat Pipe.
2.Inner Tank:SUS304-2B Food Class Stainless Steel,By Argon Arc.
3.Outer Tank:Galvanized Steel/Color Steel.
4.Bracket:Galvanized Steel/Aluminum Alloy/Stainless Steel.
5.Insulation:Polyurethane Foam.
6.Hail Resistance:30mm,50mm,80mm.
7.packing:In Standard Exported Carton.
8.Accessories:Electrical Heating,Safety Valve,Magnesium Bar,Temperature Sensor,Controller,Electrical Elements,etc.
9.Copper Heat Pipe:Heat Pipe Tubes,Thickness:0.6mm,And 140mm Condenser.Anti-freezing Function.
10.Working Pressure:Normal Working Pressure Is 6 Bar,And Testing Pressure Is 12 Bar.
2.Inner Tank:SUS304-2B Food Class Stainless Steel,By Argon Arc.
3.Outer Tank:Galvanized Steel/Color Steel.
4.Bracket:Galvanized Steel/Aluminum Alloy/Stainless Steel.
5.Insulation:Polyurethane Foam.
6.Hail Resistance:30mm,50mm,80mm.
7.packing:In Standard Exported Carton.
8.Accessories:Electrical Heating,Safety Valve,Magnesium Bar,Temperature Sensor,Controller,Electrical Elements,etc.
9.Copper Heat Pipe:Heat Pipe Tubes,Thickness:0.6mm,And 140mm Condenser.Anti-freezing Function.
10.Working Pressure:Normal Working Pressure Is 6 Bar,And Testing Pressure Is 12 Bar.
Features:
1.Pipeline Is Made Of All Red Copper And Conducted By Heat Transfer Medium Liquid.
2.Temperature Preservation Is Equipped With Standard Electric Water Heater Setting,Automatic Temperature Control Exchanger,And
Increase Anode Magnesium Bars Sticking To Prevent Furring.
3.The Insulating Layer Uses Polyurethane Bulk And Has A Good Effect Of Temperature Preservation.
4.Stable And Reliable Performance.
5.Fashion And Beautiful.
6.Environmental Protection And Energy Saving.
2.Temperature Preservation Is Equipped With Standard Electric Water Heater Setting,Automatic Temperature Control Exchanger,And
Increase Anode Magnesium Bars Sticking To Prevent Furring.
3.The Insulating Layer Uses Polyurethane Bulk And Has A Good Effect Of Temperature Preservation.
4.Stable And Reliable Performance.
5.Fashion And Beautiful.
6.Environmental Protection And Energy Saving.
Working Principle:
1. The collector absorbs solar energy and transmits it to the water tank through circulation
2. When the temperature of the collector reaches the set value, the controller starts the circulation pump automatically
3. The circulation pump makes heat-conducting liquid circulate automatically
4. The heat-conducting liquid transfers heat to water by lower heat exchanger in the water tank.
5. When the temperature difference between solar collector and tank doesn't reach the set value, the circulation pump will be shut
automatically
6. In case the temperature of the water tank does not reach Tmax, Electric Heating Element will start to work automatically
2. When the temperature of the collector reaches the set value, the controller starts the circulation pump automatically
3. The circulation pump makes heat-conducting liquid circulate automatically
4. The heat-conducting liquid transfers heat to water by lower heat exchanger in the water tank.
5. When the temperature difference between solar collector and tank doesn't reach the set value, the circulation pump will be shut
automatically
6. In case the temperature of the water tank does not reach Tmax, Electric Heating Element will start to work automatically
