Gas Lightning Protection Discharge Tube
The gas lightning protection discharge tube complies with the RoHS standard, bilateral symmetrical, little attenuation in the on/off state, the leakage current before the clamping voltage is about zero, low electrode capacitance (≤1.0pF) and high isolation (≥100MΩ), temperature, Humidity and brightness are not sensitive, working temperature range: -45℃~+85℃; temperature range: -45℃~+85℃, can withstand repeated lightning strikes without causing damage.
Features of gas lightning protection discharge tube:
Passed the lead-free certification
bilaterally symmetric
The attenuation in the on/off state is smaller
Leakage current before damping voltage is about zero
Super lightning resistance
Low electrode capacitance (s1.0pF) and high isolation (≥100m ω)
Insensitive to temperature, humidity and brightness
Working temperature range: -45℃~+85℃
Storage temperature range: -45℃- +85℃
Advantages of gas lightning protection discharge tube:
Ultra small size, low leakage current, low capacitance value, high insulation resistance, ability to withstand repeated surges, and RoHS compliant.
Application of gas lightning protection discharge tube:
Power shortage
Motor spark elimination
Relay switch spark absorption
Data line pulse protection
Electronic equipment that requires UL497A and UL497B
Phone/fax/modem
High frequency signal transmitter/receiver
Satellite Antenna
Broadcast amplifier
Alarm system
Cathode ray tube in display/TV viewing system
Part number code:
For more parameters, please call us~
Ruilongyuan Electronics Co., Ltd. We are a manufacturer of electronic components in China, the brand is RUILON, the ex-factory price, and there is no middleman. New original, Price and quality are guaranteed. if you are interest, please contact us at any moment!
Main Products:
Transient Voltage Suppressors(TVS)
Thyristor Surge Suppressors(TSS)
Protection Device TVS/ESD Arrays
Glass Gas Discharge Tubes (GGD)
Positive Thermal Coefficent (PTC)
Metal Oxide Varistors (MOV)
Surge Protective Device (SPD)
