Small excavators are widely used:
1. Orchard: digging fertilizer ditch, planting trees, weeding, soil cultivation, land reclamation, etc;
2. Trenching: cable trench, tap water or sewage pipeline, natural gas pipeline, dry toilet reconstruction, etc
3. Landscaping: tree planting, trenching, etc;
4. Mountain contracting: planting trees, building terraces, digging ditches, opening paths, weeding and opening up wasteland, etc;
5. Indoor: indoor demolition, basement backfilling;
6. Crushing: Highway and ground concrete crushing, stone crushing on the mountain, etc;
7. Mine: tunnel and cave, water conservancy culvert construction, various mines and shafts, etc;
8. Vegetable shed: used for deep soil turning;
9. Digging herbs: used for digging yams, etc;
10. Farm manure cleaning;
| Rated power | 19.1/2400 kW / rpm |
| Bucket capacity | 0.07m3 |
| Engine model | laidong km385b |
| Working weight | 1750kg |
| Maximum digging force | 11kn |
| Pump type | triple gear pump |
| Pump maximum flow | 10.10.4l/min |
| Set working pressure | 16MPa |
| Rotation speed | 10-12rpm |
| Traveling speed | 0-4.5km/h |
| Bucket digging force | 14KN |
Digging force of stick 10kN
Climbing capacity 35 °
Grounding: 30KPa
Scope of work
Boom length 1856mm
Stick length 980mm
Maximum excavation distance 3793mm
Maximum excavation depth 2154mm
Maximum excavation height 3050mm
Maximum unloading height 2217mm
Minimum turning radius 1820mm
Tail turning radius 1160
Maximum ground excavation distance 3690mm
Maximum vertical excavation depth 1500m
Boundary dimension
Total width 1050mm
Total height 2300mm
Total length 3800mm
Minimum ground clearance: 230mm
Track grounding length 1250mm
Track width 230mm
Logistics support: express, air, sea
1.With what guarantee?
All the product is guarantee for one year, and if you need parts when it damaged you can contact us to change.
2.How to ship?
Shipping method depends on your choices. We can support door delivery by air to airport by DHL, Fedex or UPS, and also we can do shipment to your sea port as well. The cost is different according to your location and the machine model you choose, you can ask for more courier cost details after deciding which machine to buy.
3.How to pay?
There are many payment methods available such as Alibaba, credit cards, T/T, paypal, offline payments (bank transfers).
You can choose a method which is the most convenient for you
4.Return policy
If you want to exchange the items received, you must contact us within 3 days of the receipt of your order. And you should pay the additional shipping fees incurred and the items returned should be kept in their original status.
Since your feedback is very important to our business`s development, we sincerely invite you to leave positive feedback for us if you are satisfied with our product and service. It`ll just take you 1 minute. Thank you!
