BIOBASE CN Dispensing Peristaltic Pump DPP-BT301F 0.1~350rpm Peristaltic Pump for Lab/Industry
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
2012
Annual Export Value:
Above US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
BIOBASE CN Dispensing Peristaltic Pump DPP-BT601F 0.1~600rpm Peristaltic Pump for Lab/IndustryNegotiableMOQ: 1 -
BIOBASE CN Peristaltic Pump FPP-BT101L Intelligent Flow Rate Peristaltic Pump for Lab/IndustryNegotiableMOQ: 1
-
BIOBASE CN Peristaltic Pump FPP-BT301L LCD Screen Display Flow Rate Peristaltic Pump for Lab/IndustryNegotiableMOQ: 1
-
BIOBASE CN Peristaltic Pump FPP-BT601L 0.1~600rpm Flow Rate Peristaltic Pump for Lab/IndustryNegotiableMOQ: 1
-
BIOBASE China Peristaltic Pump SPP-BT101S Medical Peristaltic Pump 2 Channels Watson Marlow Peristaltic Pump for LabNegotiableMOQ: 1
Product Description
Features:
* True color LCD display, touch screen and button operation;* LF-touch-OS software system, efficient and stable, with good
human-computer interaction mode, convenient product customization and upgrade;
* With liquid allocation, time allocation, copy allocation of three working modes;
* Pre-store five groups of assignment parameters for various working modes;
human-computer interaction mode, convenient product customization and upgrade;
* With liquid allocation, time allocation, copy allocation of three working modes;
* Pre-store five groups of assignment parameters for various working modes;
Specification
Model |
DPP-BT101F |
DPP-BT301F |
DPP-BT601F |
||
Flow Range |
0.0001 〜720ml/min |
0.006~1690ml/min |
0.006~2900ml/min |
||
Rotation Range |
0.1~150rpm |
0.1~350rpm |
0.1~600rpm |
||
Speed Resolution |
0.1 rpm |
||||
Dispensed Liquid Volume Range |
0.05ml~9999l |
||||
Dispensed Frequency Range |
1 to 999 times, "0" means infinite loop |
||||
Dispensed Interval Time |
0.1~999.9 seconds/minute/hour, time unit is adjustable |
||||
Speed Accuracy |
<±0.2% |
||||
Power Supply |
AC100~240V, 50Hz/60Hz |
||||
Power |
<30W |
<40W |
<50W |
||
External Control Interface |
External control input level 5V, 12V (standard), 24V (optional); |
||||
Communication Interface |
external control analog 0-5V (standard), 0-10V, 4-20mA (optional) RS485 communication, compatible with Modbus protocol |
||||
Working Environment |
Ambient temperature 0~40°C, relative humidity <80% |
||||
Protection Level |
IP31 |
||||
Overall Dimensions (L*W*H) |
261*180*197mm |
||||
Drive Weight |
4.5kg |
4.7kg |
4.9kg |
||
Packing Size |
430*290*320mm |
||||
Similar products
Packing & Delivery
Standard wooden Packing
Company Profile
BIOBASE was founded in 1997, focusing on development, production and management of laboratory and medical equipment. MEDFUTURE provide one-stop procurement solution which can not only reduce the resourcing cost, but also can ensure good quality and sufficient after-sale service.
BIOBASE is specialized in products of 9 areas including laboratory equipment, cleaning and disinfection equipment, laboratory safety protection product, cold chain product, medical equipment, general analytical equipment, measuring equipment, physical test equipment and some industry research equipment.
BIOBASE has excellent research team, strong quality control team, professional sales team and responsible after-sale service team, to provide you quality products and good service.
BIOBASE also made field trip to many suppliers in China, controlled the product quality strictly instead of customers, as well as strived from the suppliers to get competitive pricing. Recently, BIOBASE has confirmed many OEM partners and will keep searching for more suppliers upon customer' request.
BIOBASE would like to establish win-win business cooperation with distributors all over the world.
