Touch Screen Peristaltic Pump
Product Composition and Flow Rate Range:
| Model: | MPP-600T |
| Drive: | 600T |
| Speed: | 0.1~600 rpm |
| Pump Head: | YZ1515x,ZN15;YZ2515x,ZN25; DG1~12 (6),DG1~12 (10) ; |
| Flow Rate: | 0.007~2280 ml/min;0.17~1740 ml/min; 0.0015~45 ml/min per channel,0. 0015~33 ml/min per channel |
| Tubing: | 13# 14# 19# 16#25# 17# 18#; 15#24#;0.5*0.8 1*1 2*1 2.4*0.8 3*1 |
Drive Technical Parameters:
|
Drive |
100T |
300T |
600T |
|
Flow Rate Range |
0.007~380 ml/min |
0.007~1140 ml/min |
0.007~2280 ml/min |
|
Speed Range |
0.1~100 rpm |
0. 1~300 rpm |
0. 1~600 rpm |
|
Speed Resolution |
0.l rpm |
||
|
Flow Rate Accuracy |
<±0.5% |
||
|
Timing Range |
0.1s~9999min |
||
|
Quantitative Time |
0.001ml~9999min |
||
|
Back Suction Angle |
10°~720° |
||
|
Control Method |
Digital knob |
||
|
Display |
LCD screen |
||
|
Communication Interface |
RS232/RS485 support MODBUS protocol (RTU mode) |
||
|
Ambient Temperature |
0~40℃ |
||
|
Relative Humidity |
< 80% |
||
|
IP Rate |
lP31 |
||
|
Power Supply |
AC110V/220V±10% ,50/60Hz |
||
|
Consumption |
<22W |
<35w |
<50W |
|
External Size (W*D*H) mm |
212*135*240 |
||
|
Drive. Wight (Kg) |
6 |
6 |
6 |
1) OEM or ODM orders are allowed
2) 100% new,100% test before delivery.
3) Professional export team and quick service.
4) Good after-sale service,speed responding in 24 hours.
Why choose Medfuture China?
We are the professional laboratory and medical equipment supplier in China. We offer OEM and ODM service to our clients.
Would Medfuture China send product samples to customer?
We could send product samples to clients, but the sample product and the freight are charged.
What payment term does Medfuture China accept?
We accept T/T, L/C, Western Union and some of other payment methods. Usually, we prefer 100%T/T in advance, for special order, 40% of the total amount would be paid when place order, and the rest would be paid before shipment.
How long is the lead time?
7-14 preparation days are needed after receiving prepayment. Shipment period varies according the different destination, usually is 20-50 days. If it is urgent, air shipment or express delivery like TNT and DHL will be recommended.
How long is the validity of Medfuture China’s quotation?
Usually, the validity period of quotation is 30 days, but still depends on the changes of exchange rate and shipping cost.
How is the package of the product?
The equipment would be wrapped by soft materials to avoid vibration and would be packaged by wooden or cartoon boxes with water-proof plastic wrapper.
How is the inspection process before delivery?
Finished products will be inspected by our QC staff firstly, then will be checked by project manager. We also accepted third party inspection that arranged by clients.
