solar GPS tracker container GPS tracker GPS tracking device for asset management
Brief Introduction
JT704 is a kind of GPS tracker which is designed for container tracking and monitoring solution. Its features are listed as follow:
1. Inbuilt GPS GSM module for global locating and real time tracking.
2. With disposable battery 8000mAh, ultra low power consumption.
3. Intelligent working mode: real time tracking, and timing reporting with low frequency.
4. Waterproof IP67, suitable to outdoor hard environment.
5. Installation with special design. Device can replace the window cap and is installed on window of container. No damage to container.
6. Extended function with sensor. Device can support wireless door sensor, temperature sensor for, container door status monitoring, temperature monitoring.
Specification
|
Size |
205mm*67mm*26.5mm |
||
|
Weight |
<200g |
||
|
Housing material |
PC+ABS engineering plastic |
||
|
Waterproof grade |
IP67 |
||
|
Working temperature |
-30°C -- 70°C |
||
|
Storage temperature |
-40°C -- +85°C |
||
|
Relative humidity |
5%—95% |
||
|
Working current |
Average current <130mA av. current standby working current:<180uA |
||
|
Battery capacity |
8000mAh,3.7V Disposable Super Lithium battery |
||
|
GPS antenna |
build-in |
||
|
GSM antenna |
build-in |
||
|
SIM slot |
Micro SIM Card |
||
|
Module |
GSM module |
2G frequency band supported: GSM 850MHz/900MHz,DSC1800MHz,PCS1900MHz. communication rate: GPRS Data downward: max 85.6kbps GPRS Data upward: max 85.6kbps encoding format: CS-1,CS-2,CS-3,CS-4 embedded protocol: TCP |
|
|
GPS module |
support of American GPS global location system:
|
||
|
GPS |
|||
|
Sensitivity |
track-163 dBm re-capture-159 dBm cold start-148 dBm warm start-155dBm |
||
|
Frequency band |
GPS L1 Frequency (1575.42MHz) |
||
|
Starting speed
|
warm start<1s cold start 35s (typical value)
|
||
|
Location precision |
<10 meter |
||
